User manual Altman Spectra Star White PAR LED Light (Silver) SSSP-3K-S

Operating instructions and pdf manual for use - Altman Spectra Star White PAR LED Light (Silver) SSSP-3K-S User manual, User manual Altman Spectra Star White PAR LED Light (Silver) SSSP-3K-S, Altman, Spectra, Star, White, PAR, LED, Light, Silver, S


User manual for Altman Spectra Star White PAR LED Light (Silver) SSSP-3K-S

Altman Spectra Star White PAR LED Light (Silver) SSSP-3K-S
  • Manufacturer: Altman
  • Basic description and contents of package
  • Product classification: Lighting & Studio - Continuous Lighting - LED Lights
  • Safety instructions
  • Startup and operation of the led lights
  • Tips for setting up your Altman
  • Settings and expert assistance
  • Contact Altman service
  • Troubleshooting
  • Warranty information
We recommend checking out our discussion threads on the Altman Spectra Star White PAR LED Light (Silver) SSSP-3K-S, which address similar problems with connecting and setting up LED Lights Altman.



User manual for the Altman Spectra Star White PAR LED Light (Silver) SSSP-3K-S

The user manual for the Altman Spectra Star White PAR LED Light (Silver) SSSP-3K-S provides necessary instructions for the proper use of the product Lighting & Studio - Continuous Lighting - LED Lights.

The die-cast Altman Spectra Star White PAR 100W LED (Silver) is a rugged, lightweight, fixture with DMX control and RDM bi-directional communication capability. The luminaire uses warm white LED emitters that yield a flicker-free color temperature of 3,000K. The fully rotational lens holder conveniently accepts the included VNSP, NSP, MFL, WFL lenses, which are interchangeable without the use of tools. The removable, two slot accessory holder has a self-closing, self-locking, retaining latch for safety.

If you own a Altman led lights and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Altman Spectra Star White PAR LED Light (Silver) SSSP-3K-S in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
User manual for Altman Spectra Star White PAR LED Light (Silver) SSSP-3K-SDownload user manual for Altman Spectra Star White PAR LED Light (Silver) SSSP-3K-S
(PDF file, 0.45 MB)
Additional parameters of the Altman Spectra Star White PAR LED Light (Silver) SSSP-3K-S:
Specifications
    Housing Die-cast aluminum construction
    Materials Corrosion-resistant materials and hardware
    Yoke Rigid flat steel with locking-dog tilt handle
    Light Engine Luxeon Rebel LEDs- 100W max
    341 BTUs - 1 watt = 3.41 BTUs
    Color Temperature 3,000K
    Lens 4 Borosilicate glass 8" diameter PAR64 lenses provided (total of five lenses available).
    Fully rotational lens holder provided with three insulated finger tabs.
    Lenses interchangeable tool-free.
    360° beam rotation.
    Photometrics VSNP lens, H x V
    118 fc (1,267 lux) at 20' (6.1 m) with an 3.3 x 3.3 (1.0 x 1.0 m) beam size and 6.7 x 6.7' (2.0 x 2.0 m) field size
    NSP lens, V x H
    91 fc (979 lux) at 20' (6.1 m) with an 4.4 x 4.4 (1.3 x 1.3 m) beam size and 8.5 x 8.5' (2.6 x 2.6 m) field size
    MFL lens, H x V
    45 fc (487 lux) at 20' (6.1 m) with an 7.4 x 4.9 (2.3 x 1.5 m) beam size and 13.4 x 9.6' (4.1 x 2.9 m) field size
    WFL lens, H x V
    22 fc (237 lux) at 20' (6.1 m) with an 14 x 7.1 (4.3 x 2.1 m) beam size and 21.5 x 13.8' (6.6 x 4.2 m) field size
    Beam Angle VNSP: 9.5 x 9.5°
    NSP 12.5 x 12.5°
    MFL: 21 x 14°
    WFL 38.5 x 20°
    Field Angle VNSP: 19 x 19°
    NSP: 24° x 24°
    MFL: 37 x 27°
    WFL: 56.5° x 38°
    Light Sensitivity Lumens per Watt
    VNSP: 19.91
    NSP: 24.23
    MFL: 17.48
    WFL: 19.43
    Field lumens
    VNSP: 1,870
    NSP: 2,275
    MFL: 1,970
    WFL: 2,189
    Candela (cd)
    VNSP: 47,100
    NSP: 36,400
    MFL: 18,100
    WFL: 8,800
    Accessories Removable front-end accessory holder equipped with two slots accepting standard 10" (25.4 cm) accessories.
    Accessory holder retaining latch self-closing and self-locking for safety.
    Operating Voltage Multi-Voltage; 120-240V AC 50/60 Hz
    0.83 amps (120V) or 0.41 amps (240V)
    Color Range RGB
    Data Connector DMX-512A and RDM via 6.0' (2.0 m) 5-pin XLR male and female tails (portable units) or Smart Track adapter
    Cable 6.0' (2.0 m) total length bare end lead
    Finish Silver TGIC polyester, electrostatic application
    Dimensions 15.25 x 10.5 x 11.75" (39 x 27 x 30 cm)
    Weight 16 lb (7.26 kg)
    Packaging Info
    Package Weight 27.8 lb
    Box Dimensions (LxWxH) 20.1 x 20.1 x 18.3"
    The user manual for the Altman Spectra Star White PAR LED Light (Silver) SSSP-3K-S can be downloaded in .pdf format if it did not come with your new led lights, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Altman users keep a unique electronic library for Altman led lightss, where you can use our link to download the user manual for the Altman Spectra Star White PAR LED Light (Silver) SSSP-3K-S.

    The user manual lists all of the functions of the Altman Spectra Star White PAR LED Light (Silver) SSSP-3K-S, all the basic and advanced features and tells you how to use the led lights. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Altman service.

    If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Altman Spectra Star White PAR LED Light (Silver) SSSP-3K-S. User manuals are also available on the Altman website under Lighting & Studio - Continuous Lighting - LED Lights.
