User manual for the Arca-Swiss d4m Tripod Head with a MonoballFix Quick 870205

The user manual for the Arca-Swiss d4m Tripod Head with a MonoballFix Quick 870205 provides necessary instructions for the proper use of the product Photography - Tripods & Support - Tripod Heads.

Tilt and pivot your camera in three-dimensional space with the Arca-Swiss d4m Tripod Head with a MonoballFix Quick Release, which combines the advantages of a spherical head and a 3D tilt head in one compact system.

Small at only 3.5" high and 1.5 lb, yet comprising a 75 lb leverage weight capacity (which accounts for the added stress of a heavy lens) and unobtrusive yet functional controls, the d4m can be used on a tripod like a normal spherical head. When both X- and Y-axes are open, one can move the camera freely. But, in contrast to a spherical head, X- and Y-axis movements can also be made separately, one at a time. And, if one of these axes is fixed, movements can be performed with even more precision.

The design of this head puts the center of rotation of X and Y- tilts in the same place, making the pivoting radius of these movements very small, thus allowing users to maintain perspectives during readjustment. Also, a self-locking shock absorption feature for the swivel function allows for near total compensation of the camera's weight.



Another notable feature is the separate 360° panning devices at the top and at the base of the head. The bottom device allows for camera alignment, while the top device facilitates the performance of accurate panoramas and rotational stitching. Two spirit levels, arranged at 90° angles underneath the upper panorama adjustment, are sufficiently visible to facilitate effective leveling, even from a low viewpoint. This head is only compatible with newer Arca-Swiss MonoballFix-type camera plates.
If you own a Arca-Swiss tripod heads and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Arca-Swiss d4m Tripod Head with a MonoballFix Quick 870205 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Arca-Swiss d4m Tripod Head with a MonoballFix Quick 870205:
Specifications
    Load Capacity Leverage Weight: 75 lb / 34 kg
    Panning Range 360°, with 2 independent panning devices at top and base
    Tilt Range X-Axis: +90° -40°
    Y-Axis: +/- 40°
    Operation Manual
    Quick Release MonoballFix Quick Release
    Compatibility Arca-Swiss MonoballFix-type camera plates
    Spirit Level 2, located underneath the upper panorama adjustment and arranged at a 90 ° angle
    Height 3.5" / 90 mm
    Weight 1.5 lb / 670 g
    The user manual for the Arca-Swiss d4m Tripod Head with a MonoballFix Quick 870205 can be downloaded in .pdf format if it did not come with your new tripod heads, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Arca-Swiss users keep a unique electronic library for Arca-Swiss tripod headss, where you can use our link to download the user manual for the Arca-Swiss d4m Tripod Head with a MonoballFix Quick 870205.

    The user manual lists all of the functions of the Arca-Swiss d4m Tripod Head with a MonoballFix Quick 870205, all the basic and advanced features and tells you how to use the tripod heads. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Arca-Swiss service.

    If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Arca-Swiss d4m Tripod Head with a MonoballFix Quick 870205. User manuals are also available on the Arca-Swiss website under Photography - Tripods & Support - Tripod Heads.
