User manual for the Atlona 4 x 4 HDMI Matrix Switcher AT-H2H-44M
The user manual for the Atlona 4 x 4 HDMI Matrix Switcher AT-H2H-44M provides
necessary instructions for the proper use of the product Professional Video - Signal Processing & Distribution - Routers & Switchers.
The Atlona 4 x 4 HDMI Matrix Switcher supports up to 1080p video and 1920 x 1200 computer resolutions and can be controlled with an included remote, by RS-232, and the front panel. A free firmware update is on the agenda by Atlona to enable TCP/IP control via the switcher's Ethernet port.
This switcher manages EDID communication between sources and displays and automatically provides a compatible EDID at start up, and it features an EDID learning function that can be customized for any connected component. Audio can be de-embedded from the HDMI inputs and routed to amps or receivers by S/PDIF coaxial outputs. All lossy and lossless audio formats are supported, including Dolby TrueHD, DTS-HD Master Audio, full 3D, and ARC.
|
If you own a Atlona routers & switchers and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Atlona 4 x 4 HDMI Matrix Switcher AT-H2H-44M in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
|
Additional parameters of the Atlona 4 x 4 HDMI Matrix Switcher AT-H2H-44M:
| Bandwidth | 6.75 Gbps | | Input | 4x HDMI
1x RJ45
1x RS-232
1x 3.5 mm IR
1x USB B for firmware | | Output | 4x HDMI
4x 3.5 mm S/PDIF digital audio | | Video | Video: up to 1080p @ 60 Hz
VESA computer resolutions: up to 1920 x 1200 | | Audio | Passes through up to Dolby TrueHD or DTS-HD Master Audio | | Distance | 30 ft (9.1 m) | | Rack Size | 1 U | | Power Consumption | 20.6 W | | Operating Temperature | 32 to 104°F (0 to 40°C) | | Storage Temperature | -4 to 140°F (-20 to 60°C) | | Dimensions | 1.73 x 17.3 x 10" (4.4 x 44 x 25 cm) | | Weight | 6.45 lb (2.9 kg) | | Package Weight | 10.85 lb | | Box Dimensions (LxWxH) | 22.7 x 16.3 x 5.7" | |
