User manual for the Audeze LCD-X - High Performance Reference Planar LCDX-AA-B-LF
The user manual for the Audeze LCD-X - High Performance Reference Planar LCDX-AA-B-LF provides
necessary instructions for the proper use of the product Mobile - Headphones - Professional Headphones.
The Audeze LCD-X - High Performance Reference Planar Magnetic Headphones with Rugged Travel Case (Anodized Aluminum, Leather-Free) are designed for professional mixing, mastering, and reference level personal Hi-Fi listening when connected to a low powered external headphone amplifier or portable device. The headphones are sensitive enough to be driven by portable music players such as iPods, iPhones, and other smartphones. Instead of utilizing traditional dynamic cone drivers, the headphones implement a neodymium magnetic planar transducer design to deliver a frequency response of 5 to 50,000 Hz with a THD of less than 1%, an impedance of 70 Ω, an efficiency of 95 dB per 1 mW, and a total output SPL of over 130 dB when driven by 15 watts.
Magnetic planar technology differs from traditional dynamic cone designs by suspending a thin lightweight diaphragm within a parallel magnetic plane comprised of an array of magnets. The diaphragm is much lighter when compared to a traditional dynamic cone and has a printed circuit spread across a thin-film substrate on the surface of the diaphragm as opposed to a cone attached to a voice coil. When the audio signal from the amplifier reaches the circuit, it magnetizes the diaphragm within the field and produces sound.
The benefits of a magnetic planar design include faster transient response due to the lighter diaphragm, a wide frequency with low distortion, better heat dissipation, fewer moving parts for greater durability without the kind of sonic degradation that cones are susceptible to, and better amplifier compatibility because the circuit functions as an almost entirely restive load.
The magnetic structure creates a uniform magnetic field across the diaphragm without the need for additional ferromagnetic material traditionally found in other planar headphones to remove magnetic interference, reduce harmonic distortion, and lower overall weight. The headphones also feature Audeze's patent-pending Fazor elements that guide and manage the flow of sound through the earcups for a more enveloping sound stage and improved frequency extension.
The headphone earcups are made of anodized aluminum with leather-free micro suede earpads for listeners who prefer not to use products made from animals. They come with a ruggedized travel case, a 1/4" to 4-pin mini-XLR cable, a 4-pin XLR to dual 4-pin mini - XLR cable, and a 1/4" to 1/8" stereo adapter. They are handcrafted in the USA and a personalized frequency response graph is available through firstname.lastname@example.org.
If you own a Audeze professional headphones and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Audeze LCD-X - High Performance Reference Planar LCDX-AA-B-LF in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Audeze LCD-X - High Performance Reference Planar LCDX-AA-B-LF:
| Style || Open circumaural |
| Transducer Type || Planar magnetic |
| Magnet Type || Proprietary self-closing high-grade Neodymium design |
| Diaphragm || 6.17 square inches (39.8 square cm) |
| Maximum Power || 15 W (for 200 ms) |
| Optimal Range || 1 to 4 W |
| SPL || > 130 dB with 15 W |
| Frequency Response || 5 to 20,000 Hz, extension to 50,000 Hz |
| THD || < 1 % |
| Impedance || 20 Ω |
| Efficiency || 95 dB / 1 mW |
| Cable Length || 2.5 m (8.2 ft) |
| Weight || 21.2 oz (600 g) |
| Package Weight || 6.1 lb |
| Box Dimensions (LxWxH) || 12.047 x 10.394 x 7.165" |
The user manual for the Audeze LCD-X - High Performance Reference Planar LCDX-AA-B-LF can be downloaded in .pdf
format if it did not come with your new professional headphones, although the seller is
required to supply one. It is also quite common that customers throw out
the user manual with the box, or put the CD away somewhere and then can’t find it.
That’s why we and other Audeze users keep a unique electronic library
for Audeze professional headphoness,
where you can use our link to download the user manual for the Audeze LCD-X - High Performance Reference Planar LCDX-AA-B-LF.
The user manual lists all of the functions of the Audeze LCD-X - High Performance Reference Planar LCDX-AA-B-LF,
all the basic and advanced features and tells you how to use the professional headphones.
The manual also provides troubleshooting for common problems. Even greater
detail is provided by the service manual, which is not typically shipped with the product,
but which can often be downloaded from Audeze service.
If you want to help expand our database, you can upload a link to this website
to download a user manual or service manual, ideally in .pdf format. These pages
are created by you – users of the Audeze LCD-X - High Performance Reference Planar LCDX-AA-B-LF. User manuals are also
available on the Audeze website under Mobile - Headphones - Professional Headphones.
