User manual for the Audio Ltd. miniTX Transmitter & DX Receiver S463454/F3/5
The user manual for the Audio Ltd. miniTX Transmitter & DX Receiver S463454/F3/5 provides
necessary instructions for the proper use of the product Pro Audio - Location Sound - Wireless Systems.
The Audio Ltd. miniTX Transmitter & DX Receiver System Set (614 to 654MHz) consists of a miniTX transmitter, a DX receiver, a standard 24.0" (609.6mm) output cable, a 7-pin Binder male to XLR-3M connector, and a VT500 omni-directional lavalier microphone with Otter Box and accessories.
The miniTX Transmitter is a compact and lightweight professional UHF transmitter that can be easily hidden in a tiny pouch. Devoid of any switches or menu screens, this slim transmitter can be easily mounted on professionals such as artists, costumers, and sound recordists. This transmitter does not feature switches or menu screens. The IR menu can be navigated by pointing the included SwitchiR key-fob controller on the top of the miniTX Transmitter to adjust all its parameters. The microphone input via a LEMO 3-pin locking connector provides powering that is compatible with most electret lavalier microphones. Powered by 2 AAA-type batteries (sold separately), the transmitter provides up to 5 to 7 hours of transmission and can be turned off simply by removing the batteries.
The DX Compact True Diversity Receiver is a small battery-powered UHF wireless receiver designed for universal use in segments of field production sound. It offers a stellar RF range, table scanning and up to 40MHz switching bandwidth. The intuitive menu uses a blue Organic Light Emitting Diode (OLED) display that is extremely clear yet consumes very little power. All the important settings on the screen are represented by icons on the HOME screen. The receiver audio output and External DC are supported by a durable Binder 7-pin screw locking connector. The receiver is powered by a single 1.5 V AA type battery that provides up to 3 hours continuous use. An external 6 to 18 VDC power supply is connected via the Binder 7-pin connector through the output cable (sold separately). The switching takes place between two receivers at the audio frequency stage with no interruption of signal.
|
If you own a Audio Ltd. wireless systems and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Audio Ltd. miniTX Transmitter & DX Receiver S463454/F3/5 in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
|
Additional parameters of the Audio Ltd. miniTX Transmitter & DX Receiver S463454/F3/5:
| Package Weight | 8.0 lb | | Box Dimensions (LxWxH) | 15.0 x 9.0 x 3.0" | |
The user manual for the Audio Ltd. miniTX Transmitter & DX Receiver S463454/F3/5 can be downloaded in .pdf
format if it did not come with your new wireless systems, although the seller is
required to supply one. It is also quite common that customers throw out
the user manual with the box, or put the CD away somewhere and then can’t find it.
That’s why we and other Audio Ltd. users keep a unique electronic library
for Audio Ltd. wireless systemss,
where you can use our link to download the user manual for the Audio Ltd. miniTX Transmitter & DX Receiver S463454/F3/5.
The user manual lists all of the functions of the Audio Ltd. miniTX Transmitter & DX Receiver S463454/F3/5,
all the basic and advanced features and tells you how to use the wireless systems.
The manual also provides troubleshooting for common problems. Even greater
detail is provided by the service manual, which is not typically shipped with the product,
but which can often be downloaded from Audio Ltd. service.
If you want to help expand our database, you can upload a link to this website
to download a user manual or service manual, ideally in .pdf format. These pages
are created by you – users of the Audio Ltd. miniTX Transmitter & DX Receiver S463454/F3/5. User manuals are also
available on the Audio Ltd. website under Pro Audio - Location Sound - Wireless Systems.
