User manual for the Avid HD MADI Interface 9900-58834-00
The user manual for the Avid HD MADI Interface 9900-58834-00 provides
necessary instructions for the proper use of the product Pro Audio - Computer Audio - Audio Interfaces & Systems.
The Avid HD MADI digital audio interface allows the integration of Pro Tools HD into broadcast and post-production environments, and anywhere in which MADI-equipped devices are in use. HD MADI supports Pro Tools HD's 24-bit, 192 kHz audio quality. The interface allows you to send and receive up to 64 audio streams between Pro Tools HD and MADI devices, from a distance of up to 1.24 miles (2 km).
There's no need to match sample rates when using the HD MADI, because it has built-in sample-rate conversion (SRC). Its dedicated BNC Wordclock and XLR AES/EBU connections allow you to sync to an external clock when the SRC is being used on output. HR MADI's versatile clock support includes Internal, Loop Sync, Word Clock, AES/EBU, and MADI, making synchronization easy.
HD MADI's I/O features two sets of MADI ins and outs on optical connectors, two sets of MADI coaxial in and out on BNC connectors, two primary DigiLink ports, a single AES/EBU port on a single female XLR. There are also 2 SRC Wordclock In ports, and Wordclock in and out, all on BNC connectors.
|
If you own a Avid audio interfaces & systems and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Avid HD MADI Interface 9900-58834-00 in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
|
Additional parameters of the Avid HD MADI Interface 9900-58834-00:
| Sample Rates | 44.1, 48, 88.2, 96, 176.4, and 192 kHz | | Bit Depth | 24- or 16-bit | | Wordclock Support | 44.1 kHz @ 44.1 kHz
48 kHz @ 48 kHz
88.2 or 44.1 kHz @ 88.2 kHz
96 or 48 kHz @ 96 kHz
176.4 or 44.1 kHz @ 176.4 kHz
192 or 48 kHz @ 192 kHz | | Connectors | 2 x Optical MADI In
2 x BNC MADI In
2 x Optical MADI Out
2 x BNC MADI Out
2 x DigiLink Primary
1 x XLR AES/EBU (clock input only)
1 x BNC Loop Sync In
1 x BNC Loop Sync Out
2 x BNC SRC Wordclock In
1 x BNC Wordclock In
1 x BNC Wordclock Out | | Channels | Up to 64 MADI optical at 44.1 and 48 kHz | | Power | 100 to 240 VAC (auto power-selecting) | | Dimensions | 19" (48.26 cm) (width) x 1RU | | Weight | Not Specified by Manufacturer | | Package Weight | 14.0 lb | | Box Dimensions (LxWxH) | 22.2 x 15.0 x 7.5" | |
