User manual for the B W 43mm Close-up 5 Lens (NL5) 65-076587
The user manual for the B W 43mm Close-up 5 Lens (NL5) 65-076587 provides
necessary instructions for the proper use of the product Photography - Filters - Close-up Lens Filters.
The B+W 43mm Close-up +5 Lens (NL5) is a close-up diopter lens which allows you to decrease the minimum focus distance on any lens, in turn increasing the effective maximum reproduction ratio of your lens. Additionally, you can combine close-up lenses to increase their strength and to fine tune your close-up settings.
With a +5 diopter, the NL 5 serves for the seamless extension of the range provided by the NL 3 close-up lens on a 35mm main lens (up to approx. 1:3.5). If you can tolerate a small gap after the NL2 close-up lens on a 50mm main lens (approx. 1:4.4-1:4), then you enter a little farther into the macro range with the NL 5 instead of the NL 4 (up to approx. 1:2.6).
B+W filters are constructed from high quality Schott glass for increased optical clarity and color fidelity. This filter has a single anti-reflective coating, which helps to improve light transmission to over 98% while preventing internal reflections and ghosting. Additionally, it features a brass filter ring for increased durability as well as jamming prevention.
If you own a B+W close-up lens filters and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the B W 43mm Close-up 5 Lens (NL5) 65-076587 in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the B W 43mm Close-up 5 Lens (NL5) 65-076587:
| Type || Close-up lens/diopter |
| Size || 43 mm |
| Dioptric Strength || +5 |
| Filter Factor || N/A |
| Multi-Coated || Single coated |
| Effect || Decreases minimum focus distance on any lens |
| Construction || Schott glass |
| Front Filter Thread Size || 43 mm |
| Front Lens Cap Size || 43 mm |
| Package Weight || 0.2 lb |
| Box Dimensions (LxWxH) || 2.6 x 2.6 x 0.6" |
