User manual for the Bosch LTC 4745/00 Receiver (Rack, 1310 nm) F.01U.503.409
The user manual for the Bosch LTC 4745/00 Receiver (Rack, 1310 nm) F.01U.503.409 provides
necessary instructions for the proper use of the product Surveillance - Surveillance Video - Video Transmission - Signal Extenders.
The Bosch LTC 4745/00 Receiver (Rack, 1310 nm) receives CCTV analog video signals over 4 channels via one multimode fiber optic cable, and uses 8-bit video encoding that exceeds EIA RS-250C requirements for Medium Haul video transmissions. The link operates in the 1310 nm range.
|
If you own a Bosch signal extenders and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Bosch LTC 4745/00 Receiver (Rack, 1310 nm) F.01U.503.409 in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
|
Additional parameters of the Bosch LTC 4745/00 Receiver (Rack, 1310 nm) F.01U.503.409:
| Power Requirements | Powered by optional rack (LTC 4637) | | Fiber | Number of Fibers: One (1)
Optical Budget: 17 dB
Maximum Distance: 1.9 miles (3 km)
Wavelength: 1310 nm
Optical Emitter: Laser diode
Technology Type: 8-Bit digital video encoding | | Rack Mount | Occupies 2 rack slot in the optional LTC 4637 rack | | Video Bandwidth | 10 Hz to 6.5 MHz | | Differential Gain | < 2% | | Differential Phase | < 0.7° | | Tilt | < 1% | | Signal to Noise Ratio | 60 dB @ maximum optical loss budget | | MTBF | > 100,000 hours | | Weight | Approx. 2 lbs (0.9 kg) | |
