The Bosch LTC 8782/60-10 converts Bosch's biphase code into Pelco specific RS-422 control signals. This will allow Pelco cameras to be controlled from Bosch Allegiant controllers. This converter offers 4 independent Pelco outputs and uses front panel LEDs to indicate the status of power, receive and transmit.
If you own a Bosch data transmission and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Bosch LTC 8782/60-10 Allegiant Biphase to Pelco F.01U.503.552 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Bosch LTC 8782/60-10 Allegiant Biphase to Pelco F.01U.503.552:
Inputs Biphase x1 (3-pin screw terminal)
Outputs Pelco x4 (3-pin screw terminal)
Power Requirements 9-15VDC or 9-15VAC
Power Consumption 75mA
Dimensions (WxHxD) 19 x 1.8 x 5.5" (483 x 46 x 140mm)
Weight 1.5 lbs (0.7kg)
