User manual for the Canare NK-AD1 Barrel Adapter NK-AD1
The user manual for the Canare NK-AD1 Barrel Adapter NK-AD1 provides
necessary instructions for the proper use of the product Professional Video - Cables - Video Connectors.
The Canare NK-AD1 Barrel Adapter is used to enlarge the terminal area space of the plug contact. This adapter is assembled between the endbell of the plug and barrel, and fixed with a screw. This barrel adapter is useful when there is difficulty in termination. It is used with computers, office appliances, telecommunication devices, measuring equipment, audiovisual equipment, home electric appliances, and factory automation equipment.
|
If you own a Canare video connectors and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Canare NK-AD1 Barrel Adapter NK-AD1 in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
|
Additional parameters of the Canare NK-AD1 Barrel Adapter NK-AD1:
| Compatible With | NK-27-21C-3 / 4-R / 7 / 8-R and NK-27-22C-3 / 4-R / 7 / 8-R connectors | | Diameter | 1.5" (38.1 mm) | | Length | 1.34" (34.1 mm) | |
