User manual Canon EOS 5D Mark III DSLR Camera (Body Only) 5260B002

Operating instructions and pdf manual for use - Canon EOS 5D Mark III DSLR Camera (Body Only) 5260B002 User manual, User manual Canon EOS 5D Mark III DSLR Camera (Body Only) 5260B002, Canon, EOS, 5D, Mark, III, DSLR, Camera, Body, Only, 5260B002,


User manual for Canon EOS 5D Mark III DSLR Camera (Body Only) 5260B002

Overall rating 5.0
Overall Rating: 5.0

100% of respondents would recommend this to a friend.
Canon EOS 5D Mark III DSLR Camera (Body Only) 5260B002
  • Manufacturer: Canon
  • Basic description and contents of package
  • Product classification: Photography - Digital Cameras - DSLR Cameras
  • Safety instructions
  • Startup and operation of the dslr cameras
  • Tips for setting up your Canon
  • Settings and expert assistance
  • Contact Canon service
  • Troubleshooting
  • Warranty information
Canon EOS 5D Mark III DSLR Camera (Body Only) 5260B002 Canon EOS 5D Mark III DSLR Camera (Body Only) 5260B002 Canon EOS 5D Mark III DSLR Camera (Body Only) 5260B002 Canon EOS 5D Mark III DSLR Camera (Body Only) 5260B002 Canon EOS 5D Mark III DSLR Camera (Body Only) 5260B002 Canon EOS 5D Mark III DSLR Camera (Body Only) 5260B002 Canon EOS 5D Mark III DSLR Camera (Body Only) 5260B002 Canon EOS 5D Mark III DSLR Camera (Body Only) 5260B002 Canon EOS 5D Mark III DSLR Camera (Body Only) 5260B002
Click to enlarge image

We recommend checking out our discussion threads on the Canon EOS 5D Mark III DSLR Camera (Body Only) 5260B002, which address similar problems with connecting and setting up DSLR Cameras Canon.



User manual for the Canon EOS 5D Mark III DSLR Camera (Body Only) 5260B002

The user manual for the Canon EOS 5D Mark III DSLR Camera (Body Only) 5260B002 provides necessary instructions for the proper use of the product Photography - Digital Cameras - DSLR Cameras.

The Canon EOS 5D Mark III DSLR Camera is a full-frame 22.3MP DSLR featuring exceptional still image and movie recording capabilities. Integrating Canon's new DIGIC 5+ Image Processor and 14-bit A/D conversion, this camera is able to produce superbly detailed imagery with immense low-light sensitivity that is further aided by an extended ISO range up to 102400. Image quality is further enhanced by the new 61-point high density reticular autofocus, including up to 41 cross-type AF points and 5 dual diagonal AF points for ensured sharpness. iFCL metering works in conjunction with the AF system and uses color information from scenes to produce accurate exposure readings using a 63 zone dual-layer metering sensor. HDR and Multiple Exposure modes provide greater creative opportunities and help you to reduce the amount of post-production time needed to produce high quality imagery. The 5D Mark III is also capable of recording full HD video with manual exposure control and in multiple frame rates, including 1080/30p and 720/60p. Still images can also be recorded up to 6fps.

Image review is possible using the 1,040,000-dot 3.2" Clear View II LCD monitor, which features a high-transparency, reflection resistant multi-coating for adequate viewing under bright conditions. The Intelligent Viewfinder also integrates a superimposed LCD providing you with exposure information and features a 100% field of view.

A highly durable magnesium-alloy body surrounds the components and offers increased dust and weather resistance. An updated EOS Integrated Cleaning system also helps to reduce and remove dust within the camera body. Several of the physical controls on the camera body are fully customizable for a more efficient workflow and more convenient handling scheme. Dual CF and SD memory card support also increases the compatibility of the camera. Support is also provided for the optional Canon Wireless File Transmitter and GPS receiver for remote logging, tracking, and sending of your imagery.
If you own a Canon dslr cameras and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Canon EOS 5D Mark III DSLR Camera (Body Only) 5260B002 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
User manual for Canon EOS 5D Mark III DSLR Camera (Body Only) 5260B002Download user manual for Canon EOS 5D Mark III DSLR Camera (Body Only) 5260B002
(PDF file, 18.12 MB)
Additional parameters of the Canon EOS 5D Mark III DSLR Camera (Body Only) 5260B002:
Specifications
    Imaging
    Lens Mount Canon EF
    Camera Format Full-Frame (1.0x Crop Factor)
    Pixels Actual: 23.4 Megapixel
    Effective: 22.3 Megapixel
    Max Resolution 22.1 MP: 5760 x 3840
    Aspect Ratio 3:2
    Sensor Type / Size CMOS, 36 x 24 mm
    File Formats Still Images: JPEG, RAW
    Movies: MOV, MPEG-4 AVC/H.264
    Audio: Linear PCM
    Bit Depth 14-bit
    Memory Card Type CompactFlash
    SD
    SDHC
    SDXC
    Focus Control
    Focus Type Auto & Manual
    Focus Mode Continuous-servo AF (C), Manual Focus (M), Single-servo AF (S)
    Autofocus Points 61
    Viewfinder/Display
    Viewfinder Type Pentaprism
    Viewfinder Coverage 100%
    Viewfinder Magnification Approx. 0.71x
    Diopter Adjustment - 3.0 to +1.0 m
    Display Screen 3.2" Rear Screen   LCD (1,040,000)
    Screen Coverage 100%
    Exposure Control
    ISO Sensitivity 100-25600 (High Sensitivity Mode: 50-102400)
    Shutter Type: Mechanical
    Speed: 1/8000 - 30 second
    Remote Control RS-80N3, LC-5 & RC-6 (Optional)
    Mirror Lock-Up Yes
    Metering Method Average metering, Center-weighted average metering, Multi-zone metering, Spot metering
    Exposure Modes Modes: AE Lock, Aperture Priority, Auto, Manual, Programmed Auto, Shutter Priority
    Compensation: -5 EV to +5 EV (in 1/3 EV steps)
    White Balance Modes Auto, Cloudy, Custom, Daylight, Flash, Fluorescent (White), Kelvin, Manual, Shade, Tungsten
    Flash
    Built-in Flash No
    Max Sync Speed 1 / 200 seconds
    Flash Compensation -3 EV to +3 EV (in 1/3 or 1/2 EV steps)
    External Flash Connection Hot Shoe, PC Terminal
    AV Recording
    Video Recording Yes
    File Size 1920 x 1080 (Full HD)
    1280 x 720
    640 x 480
    Frame Rate @ 1920 x 1080: 30 fps, 25 fps, 24 fps
    @ 1280 x 720: 60 fps, 50 fps
    @ 640 x 480: 30 fps, 25 fps
    Exposure Control Manual: Shutter Speed, Aperture, ISO
    ISO Sensitivity 100 - 12800, Expandable to 25600
    Exposure Compensation -3 EV to +3 EV (in 1/3 EV steps)
    Focus Auto
    Manual
    Audio Recording Optional External Mic: With Video, Stereo
    Performance
    Continuous Shooting Up to 6.0 fps
    Start-up Time 0.1 seconds
    Shutter Lag 0.059 seconds
    Self Timer 2 seconds, 10 seconds
    Interval Recording Not Specified By Manufacturer
    Connectivity 1/8" Headphone
    1/8" Microphone
    AV Output
    HDMI C (Mini)
    USB 2.0
    Wi-Fi Capable Yes
    Power
    Battery 1x LP-E6 Rechargeable Lithium-ion Battery Pack, 7.2 VDC, 1800 mAh
    AC Power Adapter AC Adapter Kit ACK-E6 (Optional)
    Operating/Storage Temperature Operating
    32 to 104°F (0 to 40°C)
    Humidity: 0 - 85%
    Physical
    Dimensions (WxHxD) 6.0 x 4.6 x 3.0" / 15.2 x 11.7 x 7.6 cm
    Weight 1.89 lb / 860 g
    Packaging Info
    Package Weight 4.45 lb
    Box Dimensions (LxWxH) 9.8 x 7.2 x 5.9"
    B&H Hands-on Learning Videos
    1. Introduction 8:16
    2. Image Quality 1:56
    3. White Balance 4:32
    4. Exposure 9:26
    5. Focus Modes 5:18
    6. Image Playback 3:23
    7. Metering Modes 2:12
    8. Shooting Video 3:49
    9. Quick Tips 5:01
    10. Troubleshooting 1:21
    11. Bonus 5:27
    Canon 5D Mk. III Demo
    B&H Event Space
    Features of DSLR
    The user manual for the Canon EOS 5D Mark III DSLR Camera (Body Only) 5260B002 can be downloaded in .pdf format if it did not come with your new dslr cameras, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Canon users keep a unique electronic library for Canon dslr camerass, where you can use our link to download the user manual for the Canon EOS 5D Mark III DSLR Camera (Body Only) 5260B002.

    The user manual lists all of the functions of the Canon EOS 5D Mark III DSLR Camera (Body Only) 5260B002, all the basic and advanced features and tells you how to use the dslr cameras. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Canon service.

    If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Canon EOS 5D Mark III DSLR Camera (Body Only) 5260B002. User manuals are also available on the Canon website under Photography - Digital Cameras - DSLR Cameras.
