The Cartoni L103 Spinhead with Pan Bar, Short Handle, & Euro-Style Quick Release Plate consists of a SpinHead, pan bar, short handle, and Euro-style quick release plate. The Spinhead is a support head for any film or video camera weighing up to 33 lb (15kg). Its L-shape configuration allows you to operate at nodal setting (coincidence of the rotation center with the optical center) on a tripod, dolly, camera cars, or under slung from a crane or jib arm.

Both pan and tilt movements are assisted by continuous fluid drag units. These fluid drag modules are hollow in the center in order to allow cables and plugs. The spinning tilt unit offsets the camera allowing you to pivot the camera plate for 360° movement and lock it at any angle you may desire. All settings are easily accessible and the spinhead is comfortable to operate. The camera can be centered on board with micrometric cranks. Camera attachment is achieved by a Euro-style quick release plate.
If you own a Cartoni pan/tilt heads for cranes and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Cartoni L103 Spinhead with Pan Bar, Short Handle, & L103 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Cartoni L103 Spinhead with Pan Bar, Short Handle, & L103:
Compatibility SpinHead:
A914 Euro-Style Camera Plate Assembly
A842 Telescopic Pan-Bar for Delta, C20-S, e-Sensor, and SpinHead
A919 Cine-Style Camera Plate Assembly
A920 Video Base Plate Assembly
A904 Long Camera Plate for HiDV, Focus, SmartHeaD, and SpinHeaD
A842/A Pan-Bar Attachment for Laser, Gamma, Delta, C20-S, e-Sensor, Master, C40-S, and SpinHeaD
A849 150 mm Bowl Base for C40-S, C60-S, Sigma, SpinHeaD, and Lambda)
T624, T624/2CM, T624/2C, T624/2, T624/CM, T624/C, and T624/M OB Tripods

A914 Euro-Style Camera Plate Assembly and A842 Telescopic Pan-Bar are included.

Payload Capacity 0 to 33 lb (0 to 15 kg)
Pan/Tilt/Spin Range 360°
Fluid Drag Continuous
Base Flat Mitchell standard
Compatible with Vinten 4 holes
Temperature Range -40 to 158°F (-40 to 60°C)
Bowl Diameter 150 mm
Weight 22 lb (10 kg)
The user manual for the Cartoni L103 Spinhead with Pan Bar, Short Handle, & L103 can be downloaded in .pdf format if it did not come with your new pan/tilt heads for cranes, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Cartoni users keep a unique electronic library for Cartoni pan/tilt heads for craness, where you can use our link to download the user manual for the Cartoni L103 Spinhead with Pan Bar, Short Handle, & L103.
