User manual for the Da-Lite Yorkshire 25" Floor Lectern 75945HMVBS
The user manual for the Da-Lite Yorkshire 25" Floor Lectern 75945HMVBS provides
necessary instructions for the proper use of the product A/V Presentation - Lecterns, Podiums & Timers - Lecterns & Podiums.
The Da-Lite Yorkshire 25" Floor Lectern with Electric Height Adjustment and Gooseneck Microphone features a honey maple veneer, brass trim running down the front edges, and built-in sound system. The unit's electrically operated height ranges from 47 to 55" to accommodate the height of the speaker. The large reading surface will hold a 3-ring binder, and a rear storage shelf provides space for collateral material.
|
If you own a Da-Lite lecterns & podiums and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Da-Lite Yorkshire 25" Floor Lectern 75945HMVBS in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
|
Additional parameters of the Da-Lite Yorkshire 25" Floor Lectern 75945HMVBS:
| Construction | Wood
Rectilinear design | | Finish | Honey maple veneer
Brass trim | | Adjustments | Height: 47 to 55" (119 to 140 cm) | | Sound System | AmpliVox amp
Rated Power Output: 70 watts continuous
Max SPL @ Rated Power: 107 dB @ 1 meter
Frequency Response: 65 Hz - 15 kHz, +/- 3dB | | Microphone | Dynamic gooseneck | | Speaker | One; 70 W @ 4 ohms, switched, 1/4" phone
6.5" (16.5 cm) woofer
High-output tweeter | | Connectors | Two 110-125 V, 50/60 Hz outlets
Lectern Mic Input: Lo-Z, balanced, phantom power, XLR
Auxiliary Mic Input: Lo-Z, balanced, phantom power, XLR
Line Input: Hi-Z, unbalanced, 1/4" phone
Line Sensitivity for Rated Output (Mic): -52 dBV (2.5 mVrms)
Line Sensitivity for Rated Output (Line): -14 dBV (200 mVrms)
Mic Output (Post Fader): Lo-Z, transformer balanced, XLR
Line Output (Post Fader): Buffer isolated, 1/4" jack on amp housing
Two aux speaker outputs (ext "A" and "B" with 1/4" jacks)
| | Electrical Components | High-intensity reading light
LED clock/timer with countdown function | | Controls | Electric height
Switch for lamp on/off
Clock/timer
Speaker on/off
Mic volume
Bass/treble | | Casters | Two; non-lockable | | Power Requirements | 115-125 VAC, 60 Hz
Includes 12' (4 m) power cord suitable for a North American outlet | | Power Consumption | Not specified | | Shelf | 22.5 x 9.5 x 21.0" (57 x 24 x 53 cm) | | Reading Surface | 22.5 x 15.5" (57.0 x 39.0 cm) | | Dimensions | 25 x 47 x 22" (64 x 119 x 56 cm) | | Weight | 163 lb (74 kg, approx) | | Package Weight | 193.0 lb | | Box Dimensions (LxWxH) | 57.0 x 32.0 x 28.0" | |
