User manual for the dbx 2231 - Dual Channel 31-Band Graphic Equalizer DBX2231V
The user manual for the dbx 2231 - Dual Channel 31-Band Graphic Equalizer DBX2231V provides
necessary instructions for the proper use of the product Pro Audio - Recording - Equalizers.
The 2231 is a dual channel, 31 band 1/3 octave graphic equalizer with a difference. In addition to the usual features such as 45mm center detented sliders with selectable boost/cut range, high pass filters, active balanced input and output connections, variable input level controls, clip level indicators, and internal power supply, the unit provides both built-in noise reduction, and peak limiting.
|
If you own a dbx equalizers and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the dbx 2231 - Dual Channel 31-Band Graphic Equalizer DBX2231V in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
|
Additional parameters of the dbx 2231 - Dual Channel 31-Band Graphic Equalizer DBX2231V:
| Filter Type | Graphic | | Number of Channels | 2 | | Inputs | 2 x XLR, 2 x 1/4" TRS phone, barrier strip | | Output | 2 x XLR, 2 x 1/4" TRS phone, barrier strip | | Maximum Input Level | +21dBm | | Frequency Bands | 31 x 2, 20Hz to 20kHz ISO spacing | | Bandwidth | 1/3 octave | | Range (Boost/Cut) | +/-6dB or +/-15dB selectable | | Maximum Output Level | +21dBm | | Frequency Response | 10Hz to 50kHz | | Dynamic Range | >120dB unweighted, noise reduction in
>112dB unweighted, noise reduction out (+/-6dB range)
>108dB unweighted, noise reduction out (+/-15dB range) | | Noise | >102dB unweighted, noise reduction in
>94dB unweighted, noise reduction out (+/-6dB range)
>90dB unweighted, noise reduction out (+/-15dB range) | | Dimensions | 3U rack, 7 15/16" deep | | Specialties | Graphic equalizer/limiter with Type III noise reduction | | Package Weight | 13.95 lb | | Box Dimensions (LxWxH) | 22.0 x 11.6 x 7.6" | |
The user manual for the dbx 2231 - Dual Channel 31-Band Graphic Equalizer DBX2231V can be downloaded in .pdf
format if it did not come with your new equalizers, although the seller is
required to supply one. It is also quite common that customers throw out
the user manual with the box, or put the CD away somewhere and then can’t find it.
That’s why we and other dbx users keep a unique electronic library
for dbx equalizerss,
where you can use our link to download the user manual for the dbx 2231 - Dual Channel 31-Band Graphic Equalizer DBX2231V.
The user manual lists all of the functions of the dbx 2231 - Dual Channel 31-Band Graphic Equalizer DBX2231V,
all the basic and advanced features and tells you how to use the equalizers.
The manual also provides troubleshooting for common problems. Even greater
detail is provided by the service manual, which is not typically shipped with the product,
but which can often be downloaded from dbx service.
If you want to help expand our database, you can upload a link to this website
to download a user manual or service manual, ideally in .pdf format. These pages
are created by you – users of the dbx 2231 - Dual Channel 31-Band Graphic Equalizer DBX2231V. User manuals are also
available on the dbx website under Pro Audio - Recording - Equalizers.
