User manual for the DJI Phantom 3 Advanced Quadcopter with 2.7K Camera CP.PT.000160

The user manual for the DJI Phantom 3 Advanced Quadcopter with 2.7K Camera CP.PT.000160 provides necessary instructions for the proper use of the product .

A complete 2.7K camera and 3-axis gimbal system come integrated with the Phantom 3 Advanced edition quadcopter from DJI. In addition to video, the camera is capable shooting up to 12 MP still photos using JPEG or non-proprietary DNG RAW format. The three axes of the gimbal give you pan and tilt control, and keep the horizon line level even as the aircraft banks. Different gimbal settings allow the camera to lock onto a fixed subject, be moved manually using transmitter rotaries or the app, or to simply provide camera stabilization.

This bundle of the Phantom 3 is classed as "ready-to-fly." This means the basics to get you in the air are included - a flight battery, charger, and pre-bound handheld transmitter (radio controller), and 16GB microSD card among them. Depending on you application, you may also require additional memory cards, additional flight batteries, and a mobile device to access the app, and possibly other accessories. Also note that a number of important compass and GPS calibration steps must be carried out before flying to ensure the flight control computer operates correctly. Please refer to the manual or Quick Start Guide before your first flight.
If you own a DJI and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the DJI Phantom 3 Advanced Quadcopter with 2.7K Camera CP.PT.000160 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the DJI Phantom 3 Advanced Quadcopter with 2.7K Camera CP.PT.000160:
Specifications
Performance
Maximum Speed Ascent: 16.4' fps / 5 m/s
Descent: 9.8' / 3 m
Hover Accuracy Vertical: ±3.9" / 10 cm
Horizontal: ±3.3' / 1 m
Maximum Altitude Above Sea Level: 19,685' / 6000 m
Flight Time 23 minutes (depending on conditions)
Flight Control System
GPS Mode GPS / GLONASS
Vision Positioning Frequency: 50 Hz
Velocity Range: Below 26.2 fps / 8 m/s (6.6' / 2 m above the ground)
Altitude Range: 11.8" to 118.1" / 30 cm to 300 cm
Operating Range: 11.8" to 118.1" / 30 cm to 300 cm

Operating Environment: Surface with clear pattern and adequate lighting (> 15 lux)
Transmitter
Frequency 2.400 to 2.483 GHz
Communication Distance Up to 3.1 miles / 5 km (outdoors and unobstructed)
Receiver Sensitivity 1%PER: 101 dBm ±2 dBm
Transmitter Power EIRP: 20 dBm
Working Current 1.2 A at 7.4 V
Connectivity 1 x USB type A female for mobile device interface
1 x Micro-USB female for firmware updates / assistant software 1 x Charge port
Lightbridge Support Yes; compatible iOS or Android mobile device with USB required
Mobile Device Holder Compatibility: Tablet or smartphone
Operating Temperature 32 to 104°F / 0 to 40°C
Camera
Sensor Make: Sony EXMOR
Size: 1/2.3"
Resolution: 12.76 MP (12.4 MP effective)
Lens Aperture: f/2.8
FOV: 94°
Focal Length: 20 mm (35 mm equivalent)
Elements: 9
Focus: 0 to ∞
Photo Resolution Up to 12 MP (4000 x 3000)
ISO Range Video: 100 to 3200
Photo: 100 to 1600
Video Resolutions 2.7K (2704 x1520): 30p, 25p, 24p
1080p (1920 x 1080): 24p, 25p, 30p, 48p, 50p, 60p
720p (1280 x 720): 24p, 25p, 30p, 48p, 50p, 60p
Photo Modes Single Shot
Burst Shooting: 3/5/7 shots
Auto Exposure Bracketing (AEB): 3/5
Bracketed Frames at 0.7 EV Bias
Time-lapse
File Formats Video: MPEG-4 AVC/H.264 in MOV wrapper (up to 60 Mbps)
Photo: JPEG, DNG RAW
Recording Media Type: microSD/SDXC card up to 64 GB
Format: FAT32 / exFAT

Note: Class 10, UHS-1 or faster card required
Operating Temperature 32 to 104°F / 0 to 40°C
Gimbal
Number of Axes 3-axis (pitch, roll, yaw)
Control Range -90° to +30°
Motor
Type Brushless
Recommended Takeoff Weight 10.6 oz / 300 g per axis
Maximum Tension 1.8 lb / 800 g per axis
Stator Size 0.9 x 0.5" / 23 x 12 mm
Motor Velocity Constant KV: 960 rpm/V
Working Temperature 23 to 104°F / -5 to 40°C
Weight 1.9 oz / 55 g
Flight Battery
Chemistry Lithium-polymer
Capacity 4480 mAh
68 Wh
Configuration 4S
Voltage 15.2 VDC
Weight 12.9 oz / 365 g
Maximum Charging Power 100 W
Operating Temperature 32 to 104°F / 0 to 40°C
Charger Voltage: 17.4 VDC
57 W
Mobile App
Name DJI Pilot
System Requirements OS: iOS 8.0 or later; Android 4.1.2 or later

Recommended Devices:
Apple (iOS): iPhone 5s, iPhone 6, iPhone 6 Plus, iPad Air (Wi-Fi and cellular versions), iPad mini 2 (Wi-Fi and cellular versions), iPad Air 2 (Wi-Fi and cellular versions), iPad mini 3 (Wi-Fi and cellular versions)
(Note: Optimized for iPhone 5s, iPhone 6, and iPhone 6 Plus)

Samsung (Android): Galaxy Tab SM-T705C, Galaxy S6, Galaxy Galaxy S5, Galaxy Note4, Note3

Other (Android): Google Nexus 9, Google Nexus 7 II, Ascend Mate7, Huawei P8 Max, Nubia Z7 mini, Sony Xperia Z3, MI 3, MI PAD, Smartisan T1

Note: Additional devices may be compatible but have not yet been tested
General
Operating Temperature 32 to 104°F / 0 to 40°C
Dimensions Diagonal (Including Propellers): 23.2" / 590 mm
Weight Including Battery and Propellers: 2.8 lb / 1.3 kg
Packaging Info
Package Weight 9.3 lb
The user manual for the DJI Phantom 3 Advanced Quadcopter with 2.7K Camera CP.PT.000160 can be downloaded in .pdf format if it did not come with your new , although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other DJI users keep a unique electronic library for DJI s, where you can use our link to download the user manual for the DJI Phantom 3 Advanced Quadcopter with 2.7K Camera CP.PT.000160.

The user manual lists all of the functions of the DJI Phantom 3 Advanced Quadcopter with 2.7K Camera CP.PT.000160, all the basic and advanced features and tells you how to use the . The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from DJI service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the DJI Phantom 3 Advanced Quadcopter with 2.7K Camera CP.PT.000160. User manuals are also available on the DJI website under .
