The Zenmuse Z15-BMPCC 3-Axis Gimbal for Blackmagic Pocket Cinema Camera from DJI performs two key functions: keeping the camera level and providing stabilization, thus helping you transform a larger multi-rotor UAV, such as the S1000, into a platform for professional aerial video and aerial photography. Featuring ±0.02° control angle accuracy, the Z15-BMPCC supports three operation modes; two optimized for aerial video and photo use and one for FPV (first person view) applications. The gimbal is operated using a dedicated stick on your transmitter (hand-held radio controller), and the receiver must have at least four free channels that can be assigned to gimbal operation.

Each version of the Z15 Gimbal is designed for a specific camera and lens combination. This version is for the Blackmagic Pocket Cinema Camera with the Olympus M.ZUIKO Digital ED 12mm f/2.0 lens. Additionally, it is specifically balanced for this precise setup. Additions to the camera or lens, such as filters, can increase the weight and alter the weight distribution potentially damaging the gimbal.

Note: Installation may require soldering.
If you own a DJI dji accessories and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the DJI Zenmuse Z15-BMPCC 3-Axis Gimbal for Blackmagic CP.ZM.000051 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
User manual for DJI Zenmuse Z15-BMPCC 3-Axis Gimbal for Blackmagic CP.ZM.000051Download user manual for DJI Zenmuse Z15-BMPCC 3-Axis Gimbal for Blackmagic CP.ZM.000051
(PDF file, 3.21 MB)
Additional parameters of the DJI Zenmuse Z15-BMPCC 3-Axis Gimbal for Blackmagic CP.ZM.000051:
Supported Camera Blackmagic Pocket Camera
Supported Lens Olympus M.ZUIKO Digital ED 12mm f/2.0
Control Requirements At least 4 spare receiver channels
S-Bus/PPM receiver supported
Software Requirements For Assistant Software: Windows 8, 7, XP SP3 -- 32 or 64-bit
Working Current Static Current: 200 mA at 25 V
Dynamic Current: 400 mA at 25 V
Locked-Rotor Current: 4 A at 25 V
GCU BEC Output 10 A at 12 V
Transmit Power GCU Wireless Video Transmission: 1 A at 12 V
Controlled Angle Accuracy ±0.01°
Maximum Controlled Rotation Speed Pan Axis: ±130°/s
Tilt Axis: ±130°/s
Roll Axis ±30°/s
Controlled Rotation Range Pan Axis Control: ±360° continuous rotation
Tilt Axis Control: +50 to -140°
Roll Axis Control: ±40°
Power Requirements GCU: 4S to 12 S LiPo (6S if using S800)
Operating Temperature 14 to 122°F (-10 to 50°C)
Dimensions Gimbal: 9 x 8.3 x 8.3" (227 x 212 x 210 mm)
GCU: 2.5 x 1.4 x 0.8" (64.2 x 34.1 x 19.5 mm)
Weight Gimbal: 2.9 lb (1.3 kg)
GCU: 2.2 oz (63 g)
Packaging Info
Package Weight 4.45 lb
Box Dimensions (LxWxH) 10.5 x 10.2 x 9.3"
The user manual for the DJI Zenmuse Z15-BMPCC 3-Axis Gimbal for Blackmagic CP.ZM.000051 can be downloaded in .pdf format if it did not come with your new dji accessories, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other DJI users keep a unique electronic library for DJI dji accessoriess, where you can use our link to download the user manual for the DJI Zenmuse Z15-BMPCC 3-Axis Gimbal for Blackmagic CP.ZM.000051.

The user manual lists all of the functions of the DJI Zenmuse Z15-BMPCC 3-Axis Gimbal for Blackmagic CP.ZM.000051, all the basic and advanced features and tells you how to use the dji accessories. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from DJI service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the DJI Zenmuse Z15-BMPCC 3-Axis Gimbal for Blackmagic CP.ZM.000051. User manuals are also available on the DJI website under Camcorders - Aerial Imaging & Drones - DJI Accessories.
