User manual for the Eizo EV2730Q 26.5" LCD LED 1920 x 1920 Monitor EV2730QFX-BK

The user manual for the Eizo EV2730Q 26.5" LCD LED 1920 x 1920 Monitor EV2730QFX-BK provides necessary instructions for the proper use of the product Computers & Solutions - Monitors & Displays - Computer Monitors.

The black EV2730Q 26.5" LCD LED 1920 x 1920 Monitor from Eizo features 1920 x 1920 resolution to provide 78% more pixels compared with a standard widescreen 1920 x 1080 monitor. This monitor is as wide vertically as it is horizontally. With an IPS panel, the display features 300 cd/m2 brightness. This wide-angle screen can be utilized for DTP design, viewing maps, graphs, web development, programming, text and photo-editing, and Full HD video and other tasks. The monitor features multiple connectivity options that include dual link DVI, DisplayPort, and a 2-port USB 2.0 hub for maximum compatibility. It also has dual 1.0W speakers and 3.5mm stereo jack audio input and outputs.
If you own a Eizo computer monitors and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Eizo EV2730Q 26.5" LCD LED 1920 x 1920 Monitor EV2730QFX-BK in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
User manual for Eizo EV2730Q 26.5Download user manual for Eizo EV2730Q 26.5" LCD LED 1920 x 1920 Monitor EV2730QFX-BK
(PDF file, 2.98 MB)
Additional parameters of the Eizo EV2730Q 26.5" LCD LED 1920 x 1920 Monitor EV2730QFX-BK:
Panel
Type IPS
Backlight LED
Size 26.5"(67.2 cm)
Native Resolution 1920 x 1920
Aspect Ratio 1:1
Viewable Image Size H/V: 18.7 x 18.7" (47.6 x 47.6 cm)
Pixel Pitch 0.2478 x 0.2478 mm
Display Colors 16.77 million
Viewing Angles (H/V) 178°/178° (typical)
Brightness 300 cd/m2 (typical)
Contrast Ratio 1,000:1 (typical)
Response Time 5 ms (gray-to-gray) (typical)
Video Signals
Input Terminals 1x DisplayPort
1 x DVI-D (24-pin) (with HDCP)
Digital Scanning Frequency (H, V) 31 to 127 kHz, 59 to 61 Hz (VGA Text: 69 to 71 Hz, Single Link: 29 to 31 Hz)
USB
Standard USB 2.0
Function 1 x port for upstream
2-port USB hub
Audio
Speakers 2 x 1.0 W
Input Terminals 3.5 mm stereo jack
Output Terminals 3.5 mm headphone jack
Sound Adjustment Volume, power save, source (DisplayPort)
Power
Power Requirements 100 to 240 VAC, 50/60 Hz
Power Consumption Maximum: 64 W
Typical: 25 W
Power Save Mode: Less than 0.5 W
Power Management Power save (VESA DPM, DisplayPort Rev. 1.1a, and DVI DMPM), and off timer
Preset Modes FineContrast (paper, movie, sRGB, User 1, User 2)
Special Features Auto EcoView/BrightRegulator
EcoView sense
OSD Languages English, German, French, Italian, Japanese, Simplified Chinese, Spanish, Swedish, and Traditional Chinese
Environmental Requirements
Operating Temperature 41 to 95°F (5 to 35°C)
Operating Relative Humidity 20 to 80% (non-condensing)
Certifications and Standards TCO Displays 6.0, EPEAT Gold (US), TUV/Ergonomics (including ISO9241-307), TUV/GS, c-Tick, CE, CB, cTUVus, FCC-B, Canadian ICES-003-B, TUV/S, VCCI-B, EPA Energy Star, RoHS, WEEE, China RoHS, CCC, and GOST-R
Physical Specifications
Height Adjustment Range 3.97 to 5.55" (101 to 141 mm)
Tilt Up: 35°
Down: 5°
Swivel 344°
VESA Standard 100 x 100 mm
Dimensions (W x H x D) Landscape: 19.56 x 20.17 - 24.15 x 9.64" (497 x 512.5 - 613.5 x 245 mm)
Without Stand: 19.56 x 19.74 x 2.20" (497 x 501.5 x 56 mm)
Weight With Stand: 15.7 lb (7.1 kg)
Without Stand: 9.3 lb (4.2 kg)
Packaging Info
Package Weight 21.6 lb
Box Dimensions (LxWxH) 24.0 x 23.0 x 11.0"
The user manual for the Eizo EV2730Q 26.5" LCD LED 1920 x 1920 Monitor EV2730QFX-BK can be downloaded in .pdf format if it did not come with your new computer monitors, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Eizo users keep a unique electronic library for Eizo computer monitorss, where you can use our link to download the user manual for the Eizo EV2730Q 26.5" LCD LED 1920 x 1920 Monitor EV2730QFX-BK.

The user manual lists all of the functions of the Eizo EV2730Q 26.5" LCD LED 1920 x 1920 Monitor EV2730QFX-BK, all the basic and advanced features and tells you how to use the computer monitors. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Eizo service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Eizo EV2730Q 26.5" LCD LED 1920 x 1920 Monitor EV2730QFX-BK. User manuals are also available on the Eizo website under Computers & Solutions - Monitors & Displays - Computer Monitors.
