User manual Elation Professional Colour Chorus 72 Light Bar (288 LEDs)

Operating instructions and pdf manual for use - Elation Professional Colour Chorus 72 Light Bar (288 LEDs) User manual, User manual Elation Professional Colour Chorus 72 Light Bar (288 LEDs), Elation, Professional, Colour, Chorus, 72, Light, Bar, 2


User manual for Elation Professional Colour Chorus 72 Light Bar (288 LEDs)

Elation Professional Colour Chorus 72 Light Bar (288 LEDs)
  • Manufacturer: Elation Professional
  • Basic description and contents of package
  • Product classification: Lighting & Studio - Continuous Lighting - Stage & Studio
  • Safety instructions
  • Startup and operation of the stage & studio
  • Tips for setting up your Elation Professional
  • Settings and expert assistance
  • Contact Elation Professional service
  • Troubleshooting
  • Warranty information
Elation Professional Colour Chorus 72 Light Bar (288 LEDs) Elation Professional Colour Chorus 72 Light Bar (288 LEDs) Elation Professional Colour Chorus 72 Light Bar (288 LEDs) Elation Professional Colour Chorus 72 Light Bar (288 LEDs)
Click to enlarge image

We recommend checking out our discussion threads on the Elation Professional Colour Chorus 72 Light Bar (288 LEDs), which address similar problems with connecting and setting up Stage & Studio Elation Professional.



User manual for the Elation Professional Colour Chorus 72 Light Bar (288 LEDs)

The user manual for the Elation Professional Colour Chorus 72 Light Bar (288 LEDs) provides necessary instructions for the proper use of the product Lighting & Studio - Continuous Lighting - Stage & Studio.

The Colour Chorus 72 from Elation Professional is a 6'-long RGBA (red, green, blue, & amber) light bar featuring 288 individual 3W LEDs: 72 LEDs per color. The fixture offers individual hue, saturation, and intensity control; LED group control; variable dimming curve modes; and strobe & chase effects.

The Colour Chorus 72 incorporates a four-button touch-control panel and an LCD menu display. It supports three & five-pin DMX connectivity, Art-Net & Kling-Net protocols, and RDM (Remote Device Management) control. Flicker-free operation makes the unit suitable for TV and film broadcast. Multiple DMX channel modes enable you to control varying levels of features.

The fixture features a powerCON input and an internal auto-switching power supply. It is compatible with 110-250 VAC outlets and has a maximum power consumption of 630W. The Colour Chorus 72 can be mounted in any position using the integrated rigging brackets (clamps sold separately).
If you own a Elation Professional stage & studio and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Elation Professional Colour Chorus 72 Light Bar (288 LEDs) in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Elation Professional Colour Chorus 72 Light Bar (288 LEDs):
Lamp 288 x 3 W (RGBA) LEDs (red, green, blue, amber)
LED Life Expectancy Average: 100,000 hours
Photometric Data 23,000 lux (2,137 fc) @ 3.3' (1 m) 88° full-on
DMX Connectors 1 x 3-pin XLR male, DMX in
1 x 3-pin XLR female, DMX out
1 x 5-pin XLR male, DMX in
1 x 5-pin XLR female, DMX out
1 x Ethernet RJ45, Art-Net / Kling-Net in
1 x Ethernet RJ45, Art-Net / Kling-Net out
Protocols DMX512, Art-Net, Kling-Net, and RDM (Remote Device Management)
Effects Strobe and chase
Variable dimming curves
Individual hue, saturation, and intensity control
Power Connection Type 1 x powerCON, power in
1 x powerCON, power out
Power Cord Daisy Chain Yes
Power Supply 110-250 VAC, 50 / 60 Hz
Power Consumption 630 W max.
Display/Controls LCD menu display with four-button control panel
IP Rating IP30
Exterior Rugged die-cast aluminum
Operating Temperature 5 to 113°F (-15 to 45°C)
Rigging Points Integrated rigging brackets
Working Position Any (360°)
Approvals CE
cETLus
Dimensions 69.3 x 7.6 x 7.6" (1760.0 x 194.1 x 192.5 mm)
Weight 53 lb (24 kg)
The user manual for the Elation Professional Colour Chorus 72 Light Bar (288 LEDs) can be downloaded in .pdf format if it did not come with your new stage & studio, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Elation Professional users keep a unique electronic library for Elation Professional stage & studios, where you can use our link to download the user manual for the Elation Professional Colour Chorus 72 Light Bar (288 LEDs).

The user manual lists all of the functions of the Elation Professional Colour Chorus 72 Light Bar (288 LEDs), all the basic and advanced features and tells you how to use the stage & studio. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Elation Professional service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Elation Professional Colour Chorus 72 Light Bar (288 LEDs). User manuals are also available on the Elation Professional website under Lighting & Studio - Continuous Lighting - Stage & Studio.
