| Projection System | Epson 3LCD, 3-chip optical engine |
| Driving Method | Epson Poly-Silicon TFT Active Matrix
0.74" (18.8 mm) wide panel with MLA |
| Projection Method | Front
Rear
Ceiling mount |
| Brightness | 2400 lumens (color light output)
2400 lumens (white light output) |
| Contrast Ratio | Up to 600,000:1 |
| Native Resolution | Full HD 1080p (1920 x 1080) |
| Pixel Count | 2,073,600 dots (1920 x 1080 x 3) |
| Projector Output | HD
2D
3D
1080p |
| Aspect Ratio | Native: 16:9 (compatible with 4:3)
Resize: 16:10, 4:3 |
| Color Reproduction | Full-color (1.07 billion colors) |
| Color Processing | Full 10-bit
Partial 12-bit |
| Display Performance | 1920 x 1080 native (1080p)
HD
2D
3D
2D to 3D conversion |
| Color Modes | 2D: Dynamic, Living Room, Natural, THX, Cinema, B&W Cinema
3D: Dynamic, Cinema, THX |
| Cinema Filter | Automatically adjusts to color mode
On: Natural/THX/Cinema/B&W Cinema
Off: Dynamic/Living Room/3D Dynamic/3D Cinema/3D THX) |
| Auto Iris | Automatically adjusts to video source
Off/On: High-speed or Normal, 2D and 3D mode |
| Super Resolution | 2D
3D |
| Projection Lens | Type: Manual focus / Optical zoom
Aperture: f/2.3 - f/3.6
Focal Length: 22.5 - 47.2 mm
Zoom Ratio: 1.0 - 2.1 |
| Lens Shift | Vertical: ±96.3
Horizontal: ±47.1 |
| Lens Cap | Powered, Slide Lens Shutter |
| Lamp Type | E-TORL 230 W UHE |
| Lamp Life | Up to 4000 hours (Normal mode)
Up to 5000 hours (ECO mode) |
| Throw Ratio | 1.34 - 2.87:1 |
| Projection Size | 30 - 300" (76.2 - 762 cm) |
| Keystone Correction | Vertical: ±30° (manual) |
| Input Signal | Composite: NTSC, NTSC4.43, PAL, M-PAL, N-PAL, PAL60, SECAM
Component: 480i, 576i, 480p, 576p, 720p, 1080i, 1080p
HDMI: TMDS |
| Inputs | 2 x HDMI
1 x RS-232C
1 x RCA (composite)
3 x RCA (component)
1 x VGA D-sub 15-pin (computer input) |
| Outputs | Trigger On/Off (3.5 mm stereo jack)
12 VDC 200 mA (max) |
| Wireless HD Transmitter | Wireless HD Type: Beam Forming WirelessHD 1.0b 60 GHz Band (QPSK, 16-QAM, BPSK) 2-ch and 3-ch
Input: HDMI x 5 (including one MHL enabled)
Outputs: HDMI x 1, Optical Audio x 1
USB Port: USB type-A x 1 (3D glasses charging)
Wireless: FCC Part 15 Subpart C 15.255
Safety: UL 60950-1 2nd edition (cTUVus Mark)
EMC: FCC Part 15B Class B
Power Consumption: 11 V / 1.2 A
Operating Altitude: 0 to 7500 ft (0 to 2286 m)
Storage Temperature: 14 to 140°F (-10 to 60°C)
Dimensions (WxHxD): 6.9 x 2 x 5" (175 x 51 x 127 mm)
Weight: Not specified by manufacturer |
| Computer Compatibility | PC
Mac |
| Fan Noise | 22 - 32 dB |
| Security | Kensington Security Lock Port |
| Remote Control | Front directional
Rear directional
Front Operation Angle (Right/Left): ±30°
Front Operation Angle (Upper/Lower): ±30°
Rear Operation Angle (Right/Left): ±30°
Rear Operation Angle (Upper/Lower): +10/+70°
Operating Distance: 32' (10 m) |
| Parental Control | Power Button Lock (hinders projector from being turned on without parental supervision) |
| Operating Temperature | 41 to 95°F (5 to 35°C) |
| Power Supply Voltage | AC 100 - 240 V ± 10% (50/60 Hz) |
| Power Consumption | 350 W (lamp on Normal mode)
280 W (lamp on ECO mode) |
| Dimensions (WxHxD) | 18.34 x 6.2 x 15.5" (466 x 158 x 394 mm) including feet
18.34 x 5.5 x 15.6" (466 x 140 x 396 mm) excluding feet |
| Weight | 18.9 lb (8.57 kg) |
