The RedNet MP8R from Focusrite is an 8-channel remote-controlled microphone preamplifier and A/D for the Dante audio-over-IP network. The MP8R was developed from the RedNet 4 studio remote-controlled microphone preamp, and incorporated improvements from the considerable input of leading live sound practitioners during its development. The unit provides a wealth of features that make it particularly applicable to the live sound/recording and broadcast environments, and other workflows where reliability is paramount. Dual Ethernet ports with locking etherCON connectors are provided, with several operating modes including daisy-chaining and redundancy confirmed by front-panel indicators. Two separate power supplies with fault detection capability are included, with separate power input sockets (with retaining clips) on the rear of the unit. The state of each power supply is indicated both remotely and on the front panel. The MP8R features a rugged, roadworthy exterior and internal build quality. In addition, the unit offers a compact 1U rack-mount form factor. The MP8R preamps utilize Focusrite's well-known mic pre designs,with a pedigree that stretches back to the original Focusrite products of the mid-1980s. Fully keeping pace with the latest developments in audio technology, today's Focusrite preamps offer lower noise, improved dynamic range, and better Common Mode Rejection. The preamps in the MP8R offer an increased maximum input level of 28 dBu, plus a 20 dB pad, high-pass filter, polarity inversion, and phantom power. Each preamp has a dual-input impedance of 2.4 or 10 kOhms, allowing flexibility when running multiple mic pres in parallel.
|
If you own a Focusrite accessories and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Focusrite RedNet MP8R 8-Channel Remote-Controlled REDNET MP8R in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
|
Additional parameters of the Focusrite RedNet MP8R 8-Channel Remote-Controlled REDNET MP8R:
Microphone Inputs | Specifications: Gain Range: 0 to 55 dB in 1 dB steps Type: Electronically balanced, Zin = 2.4/10 kOhms (switchable) Maximum Input Level: 29 dBu ±0.5; minimum gain with pad for 0 dBFS, Rs = 150 ohms Minimum Input Level: -46 dBu ±0.5; maximum gain without pad for 0 dBFS, Rs = 150 ohms Frequency Response: 20 Hz to 55 kHz ±0.1 dB THD + N: -98 dB (0.0012%) @ -1 dBFS, Rs = 150 ohms EIN: -129 dBu 'A'-Weighted (typical), Rs = 150 ohms Signal-to-Noise Ratio: 118 dB 'A'-Weighted (typical), Rs = 150 ohms Phantom Power: +48 V, independently switchable per channel Pad: -20 dB, independently switchable per channel High Pass Filter: -6 dB @ 65 ± 3 Hz, 12 dB/Octave, independently switchable per channel Crosstalk: < -100 dB, 20 Hz to 20 kHz; minimum input gain | Connectors (Rear Panel) | 8 x XLR3 female analog audio microphone inputs 2 x etherCON locking Ethernet connectors (compatible with standard RJ45 connectors) 2 x IEC power inputs (with retaining clips) | Digital Performance | Supported Sample Rates: 44.1, 48, 88.2, 96, 176.4, 192 kHz (-4, -0.1, +0.1, +4.167%) at 24 bit Clock Sources: Internal or from network master device | Front Panel Controls | Power on/off Channel select buttons (1 to 8) Illuminated Buttons: Info, 2.4/10 kOhm input impedance, 20 dB pad, +48 V Phantom Power, HPF, and Polarity Gain setting knob | Indicators | PSU A and PSU B power supply active LEDs Network: Primary, Secondary, and Locked LEDs Sample Rate: 44.1 kHz, 48 kHz, x2, x4 and Pull LEDs 8 x 6-segment level displays Gain (dB) and status indication for selected channel via OLED display Illuminated Buttons: Info (displays device data on OLED panel) 2.4 kOhm input impedance -20 dB, +48 V, HPF, and Polarity | Network Modes | Redundant: Allows unit to connect two independent networks. Switched: Connects both ports to integrated network switch, allowing daisy-chaining of devices. | PSU | 2 x internal; IEC inputs, 100 to 240 VAC, 50/60 Hz Apparent Power: 30 VA | Dimensions (H x W x D) | 1.75 x 19 x 15.51" (44.5 x 482.6 x 394 mm) | Weight | 12.68 lb (5.75 kg) | Package Weight | 19.65 lb | Box Dimensions (LxWxH) | 26.1 x 21.968 x 4.803" | |
