User manual For.A LTR-200HS6 LTO-6 Multi Codec Archiving Recorder LTR-200HS6

Operating instructions and pdf manual for use - For.A LTR-200HS6 LTO-6 Multi Codec Archiving Recorder LTR-200HS6 User manual, User manual For.A LTR-200HS6 LTO-6 Multi Codec Archiving Recorder LTR-200HS6, For.A, LTR-200HS6, LTO-6, Multi, Codec, Arch


User manual for For.A LTR-200HS6 LTO-6 Multi Codec Archiving Recorder LTR-200HS6

For.A LTR-200HS6 LTO-6 Multi Codec Archiving Recorder LTR-200HS6
  • Manufacturer: For.A
  • Basic description and contents of package
  • Product classification: Professional Video - Recorders & Duplication - Solid State/HDD Recorders
  • Safety instructions
  • Startup and operation of the solid state/hdd recorders
  • Tips for setting up your For.A
  • Settings and expert assistance
  • Contact For.A service
  • Troubleshooting
  • Warranty information
  • Price: 25 USD
We recommend checking out our discussion threads on the For.A LTR-200HS6 LTO-6 Multi Codec Archiving Recorder LTR-200HS6, which address similar problems with connecting and setting up Solid State/HDD Recorders For.A.



User manual for the For.A LTR-200HS6 LTO-6 Multi Codec Archiving Recorder LTR-200HS6

The user manual for the For.A LTR-200HS6 LTO-6 Multi Codec Archiving Recorder LTR-200HS6 provides necessary instructions for the proper use of the product Professional Video - Recorders & Duplication - Solid State/HDD Recorders.

The LTR-200HS6 LTO-6 Multi Codec Archiving Recorder from For.A comes equipped with an LTO-6 (Linear Tape Open) drive and supports a wide range of file codecs. The Terabyte and LTFS file system recording capability of the unit allow it to be used as a material or program exchange platform. The LTR-200HS6 features HD/SD-SDI input/output, broadcast quality codecs, and MXF (OP-1a) wrapping and unwrapping. MXF files that are recorded on LTO can also be used with non-linear editing systems. Simply connect VTRs to the LTR-200HS6 to convert HD/SD-SDI signals to MXF files. The LTR-200HS6 offers a solution for repurposing past baseband data in filebase systems.
If you own a For.A solid state/hdd recorders and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the For.A LTR-200HS6 LTO-6 Multi Codec Archiving Recorder LTR-200HS6 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the For.A LTR-200HS6 LTO-6 Multi Codec Archiving Recorder LTR-200HS6:
Video Formats HD: 1080/59.94i, 1080/50i, 720/59.94p, 720/50p (select at menu)
Storage Device Type: LTO-6 (File system: IBM LTFS)
Capacity: UP to 2.5 TB (data area: 2408 GB / 2242 GiB)
Recording Capacity: MPEG-2 50Mbps MXF: Max. 80 hours
AVC-Intra 100 MXF: Max. 40 hours
DNxHD 220x MXF: Max. 18 hours
Response: File body seek time: within 3 minutes
Size: 4.1 x 0.9 x 4.0" (10.5 x 2.2 x 10.2 cm)

These recording capacities are the theoretical value excepted of ancillary data and proxy files.
These might decrease depending on the condition of tape head and tape.

MXF Files Support OP-1a (SMPTE RDD-9) HD: MPEG-2 Long GOP
50 Mbps (CBR/4:2:2/422P @ ML) Audio: 24-bit, 8 channels
35 Mbps (VBR/4:2:0/MP @ HL) Audio: 16-bit, 4 channels
25 Mbps (CBR/4:2:0/MP @ H14) Audio: 16-bit, 4 channels
18 Mbps (VBR/4:2:0/MP @ HL) Audio: 16-bit, 4 channels
OP-1a HD:
AVC-Intra 100 (10-bit, 4:2:2) Audio: 24-bit, 8 channels
AVC-Intra 50 (10-bit, 4:2:0) Audio: 24-bit, 8 channels
DVCPRO HD (8-bit, 4:2:2) Audio: 24-bit, 8 channels
DNxHD 220x (10-bit, 4:2:2) Audio: 24-bit, 8 channels
DNxHD 220 (8-bit, 4:2:2) Audio: 24-bit, 8 channels
DNxHD 145 (8-bit, 4:2:2) Audio: 24-bit, 8 channels
Video Input 1 x BNC, HD-SDI
1.5 Gbps, 75 ohms
Video Output 4 x BNC (output 3 & 4 support timecode display)
1.5 Gbps, 75 ohms
Genlock Input HD: BB: NTSC: 0.429 V p-p/PAL: 0.45 V p-p or Tri-level sync: 0.6 V p-p, 75 ohms
1 x BNC, loop-through (Terminate with 75 ohms; terminator, if unused)
AES/EBU Audio Input Max. 8 channels (4 stereo pairs) (Group 1 and 2) 48 kHz, synchronous only
HD: 1.0 V p-p, unbalanced, 75 ohms, 2 x BNC (2 stereo pairs), 48 kHz
SD: 1.0 V p-p, unbalanced, 75 ohms, 2 x BNC (2 stereo pairs), 48 kHz

The maximum number of output channels varies by MXF format and bitrate.

AES/EBU Audio Output Max. 8 channels (4 stereo pairs) (Group 1 and 2) 48 kHz, synchronous only
HD: 1.0 V p-p, unbalanced, 75 ohms, 2 x BNC (2 stereo pairs), 48 kHz
SD: 1.0 V p-p, unbalanced, 75 ohms, 2 x BNC (2 stereo pairs), 48 kHz

The maximum number of output channels varies by MXF format and bitrate.

Timecode Input Embedded: Ancillary timecode, LTC: 1.0 V p-p, unbalanced, 75 ohms, 1 x BNC
Timecode Output Embedded: Ancillary timecode, LTC: 1.5 V p-p, unbalanced, 75 ohms, 1 x BNC
Recording Time Minimum / file: 1 second, Maximum / file: 24 hours
Internal Storage 3 TB HDD
Interfaces 1 x 9-pin Sub-D female, RS-422 for external VTR control on recording
3 x USB 2.0 type A
2 x RJ45, 1000BASE-T/100BASE-TX, LAN1/2
1 x Mini-SAS, to external drive
1 x 15-pin Sub-D female, GPI/ALARM
3-input/3-output GPI, Power, Fan alarm (relay contact), GPI: (contact input, open collector output)
1 x 15-pin mini Sub-D, female VGA, maintenance only
Proxy Create with MXF file, H.264/MP4 1 Mbps or Windows Media Video 1.5 Mbps
File System Work as FTP server. Unable to access LTO at once by multiple users.
Temperature & Humidity 50 to 95°F (10 to 35°C), 20 to 80% no condensation
Power Supply 100 - 240 VAC, ±10%, 50/60 Hz
Power Consumption 210 VA (212 W) at 100 - 120 VAC
198 VA (182 W) at 220 - 240 VAC
Dimensions 8.3 x 5.1 x 21.0" (21.2 x 13.0 x 53.4 cm)
EIA 3 RU half size
Weight 22 lb (10 kg)
The user manual for the For.A LTR-200HS6 LTO-6 Multi Codec Archiving Recorder LTR-200HS6 can be downloaded in .pdf format if it did not come with your new solid state/hdd recorders, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other For.A users keep a unique electronic library for For.A solid state/hdd recorderss, where you can use our link to download the user manual for the For.A LTR-200HS6 LTO-6 Multi Codec Archiving Recorder LTR-200HS6.

The user manual lists all of the functions of the For.A LTR-200HS6 LTO-6 Multi Codec Archiving Recorder LTR-200HS6, all the basic and advanced features and tells you how to use the solid state/hdd recorders. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from For.A service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the For.A LTR-200HS6 LTO-6 Multi Codec Archiving Recorder LTR-200HS6. User manuals are also available on the For.A website under Professional Video - Recorders & Duplication - Solid State/HDD Recorders.
