User manual for the Gigabyte GA-B150M-D3H DDR3 Micro-ATX GA-B150M-D3H DDR3

The user manual for the Gigabyte GA-B150M-D3H DDR3 Micro-ATX GA-B150M-D3H DDR3 provides necessary instructions for the proper use of the product Computers & Solutions - Computer Components - Motherboards.

The Gigabyte GA-B150M-D3H DDR3 Micro-ATX Motherboard comes with an LGA 1511 socket along with Intel's Small Business Advantage technologies so you can build a reliable PC system for productivity. The LGA 1511 socket is compatible with Intel's 6th-generation series of processors, and the four DIMM slots support up to 32GB of DDR3 RAM. For storage, this motherboard lets you install a PCIe-based SSD to the M.2 connector, which utilizes multiple PCIe lanes to offer bandwidths up to 32 Gb/s. Furthermore, it features a dualBIOS design that offers a secondary backup BIOS if the main BIOS becomes corrupt.

Gigabyte has built this motherboard to deliver visuals via integrated Intel graphics along with the VGA, HDMI, and DVI ports or with dedicated graphics cards utilizing the two PCIe 3.0 slots. To complete the multimedia experience, it comes with Realtek ALC892 audio and six audio jacks. You can further expand the potential of your system by connecting external peripherals to its six USB ports. Moreover, an Ethernet LAN jack allows the system to reliably access the network and Internet at Gigabit speeds. Other notable features include six SATA connectors and a single SATA Express connector along with two PCI slots.
If you own a Gigabyte motherboards and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Gigabyte GA-B150M-D3H DDR3 Micro-ATX GA-B150M-D3H DDR3 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Gigabyte GA-B150M-D3H DDR3 Micro-ATX GA-B150M-D3H DDR3:
Specifications
Processor Supported Supports Intel Core i7, Core i5, Core i3, Pentium, and Celeron processors in the LGA1151 package
Chipset Intel B150 Express chipset
Memory 4 x DDR3 DIMM sockets supporting up to 32 GB of system memory
Dual channel memory architecture
Support for DDR3/DDR3L 1866(OC)/1600/1333 MHz memory modules
Support for ECC UDIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC UDIMM 1Rx8/2Rx8 memory modules
Onboard Graphics Integrated Intel HD Graphics supported
1 x D-Sub port, supporting a maximum resolution of 1920 x 1200 @ 60 Hz
1 x DVI-D port, supporting a maximum resolution of 1920 x 1200 @ 60 Hz
1 x HDMI 1.4 port, supporting a maximum resolution of 4096 x 2160 @ 24 Hz
Support for up to 3 displays at the same time
Maximum shared memory of 512 MB
Audio Realtek ALC892 codec
High Definition Audio
2/4/5.1/7.1-channel
Support for S/PDIF Out
LAN Intel GbE LAN chip (10/100/1000 Mbit)
Expansion Slots 1 x PCI Express 3.0 x16 slot, running at x16 (PCIEX16)
1 x PCI Express 3.0 x16 slot, running at x4 (PCIEX4)
2 x PCI slots
Multi-Graphics Technology Support for 2-Way AMD CrossFire Technology
Storage Interface 1 x M.2 Socket 3 connector
1 x SATA Express connector
6 x SATA 6 Gb/s connectors
USB 6 x USB 3.0/2.0 (4 ports on the back panel, 2 ports available through the internal USB headers)
6 x USB 2.0/1.1 (2 ports on the back panel, 4 ports available through the internal USB headers)
Internal I/O Connectors 1 x 24-pin ATX main power connector
1 x 8-pin ATX 12 V power connector
1 x M.2 Socket 3 connector
1 x SATA Express connector
6 x SATA 6 Gb/s connectors
1 x CPU fan header
3 x System fan headers
1 x Front panel header
1 x Front panel audio header
1 x S/PDIF Out header
1 x USB 3.0/2.0 header
2 x USB 2.0/1.1 headers
1 x Trusted Platform Module (TPM) header
1 x Thunderbolt add-in card connector
1 x Serial port header
1 x Parallel port header
1 x Clear CMOS jumper
Back Panel Connectors 1 x PS/2 keyboard/mouse port
1 x D-Sub port
1 x DVI-D port
1 x HDMI port
4 x USB 3.0/2.0 ports
2 x USB 2.0/1.1 ports
1 x RJ-45 port
6 x Audio jacks (center/subwoofer speaker out, rear speaker out, side speaker out, line in, line out, mic in)
I/O Controller iTE I/O controller chip
H/W Monitoring System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
CPU/System overheating warning
CPU/System fan fail warning
CPU/System fan speed control
BIOS 2 x 128 Mbit flash
Use of licensed AMI UEFI BIOS
Support for DualBIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Supported Features APP Center
Q-Flash
Smart Switch
Xpress Install
Operating System Supported Windows 7, 8.1, 10
Dimensions 9.6 x 8.9" / 24.4 x 22.5 cm
Packaging Info
Package Weight 2.0 lb
Box Dimensions (LxWxH) 10.6 x 10.5 x 2.2"
The user manual for the Gigabyte GA-B150M-D3H DDR3 Micro-ATX GA-B150M-D3H DDR3 can be downloaded in .pdf format if it did not come with your new motherboards, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Gigabyte users keep a unique electronic library for Gigabyte motherboardss, where you can use our link to download the user manual for the Gigabyte GA-B150M-D3H DDR3 Micro-ATX GA-B150M-D3H DDR3.

The user manual lists all of the functions of the Gigabyte GA-B150M-D3H DDR3 Micro-ATX GA-B150M-D3H DDR3, all the basic and advanced features and tells you how to use the motherboards. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Gigabyte service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Gigabyte GA-B150M-D3H DDR3 Micro-ATX GA-B150M-D3H DDR3. User manuals are also available on the Gigabyte website under Computers & Solutions - Computer Components - Motherboards.
