User manual GoPro HERO 4 Black CHDHX-401 HERO4 at

Operating instructions and pdf manual for use - GoPro HERO 4 Black CHDHX-401 HERO4 at User manual, User manual GoPro HERO 4 Black CHDHX-401 HERO4 at, GoPro, HERO, 4, Black, CHDHX-401, HERO4, at,


User manual for GoPro HERO 4 Black CHDHX-401 HERO4 at

Overall rating 4.5
Overall Rating: 4.5

90% of respondents would recommend this to a friend.
GoPro HERO 4 Black CHDHX-401 HERO4 at
  • Manufacturer: GoPro
  • Basic description and contents of package
  • Product classification: Camcorders - Sports & Action Cameras
  • Safety instructions
  • Startup and operation of the sports & action cameras
  • Tips for setting up your GoPro
  • Settings and expert assistance
  • Contact GoPro service
  • Troubleshooting
  • Warranty information
GoPro HERO 4 Black CHDHX-401 HERO4 at GoPro HERO 4 Black CHDHX-401 HERO4 at GoPro HERO 4 Black CHDHX-401 HERO4 at GoPro HERO 4 Black CHDHX-401 HERO4 at GoPro HERO 4 Black CHDHX-401 HERO4 at GoPro HERO 4 Black CHDHX-401 HERO4 at
Click to enlarge image

We recommend checking out our discussion threads on the GoPro HERO 4 Black CHDHX-401 HERO4 at, which address similar problems with connecting and setting up Sports & Action Cameras GoPro.



User manual for the GoPro HERO 4 Black CHDHX-401 HERO4 at

The user manual for the GoPro HERO 4 Black CHDHX-401 HERO4 at provides necessary instructions for the proper use of the product Camcorders - Sports & Action Cameras.

With the ability to capture 4K at 30 fps (4K30), the GoPro HERO4 Black allows you to move beyond HD when recording POV style footage either wearing the camera or mounting it in a number of creative ways. On top of 4K, the camera shoots 2.7K at up to 60 fps, Full HD (1080p) at up to 120 fps for high definition slow motion, WVGA (848 x 480) for upload-friendly files, and more. Plus, with the SuperView mode enabled, the camera maximizes its sensor area to give you an ultra-wide angle of view to enhance the POV feel of footage while encompassing as much of the scene as possible. The HERO4 Black's capabilities don't end with video, though. It can take 12-megapixel stills as individual shots, in intervals for stitching together time-lapse movies, or in momentary bursts of up to 30 photos per second - the latter helping ensure you catch fast action at just the right moment.

For remote monitoring and operation, the camera is equipped with Wi-Fi and Bluetooth connectivity, letting you pair it with a mobile device or the separately available Smart Remote. There is also a USB port for file transfer, charging, or to connect the optional 3.5mm mic adapter. Further promoting its take-anywhere claim, the 131' Standard Housing is included, and not only keeps the camera dry, it adds an extra layer of protection. In addition to the bundled flat and adhesive mounts, the camera is also adaptable to a wide range of separately available mounts from GoPro and third-parties - with options to accommodate just about any scenario imaginable.
If you own a GoPro sports & action cameras and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the GoPro HERO 4 Black CHDHX-401 HERO4 at in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
User manual for GoPro HERO 4 Black CHDHX-401 HERO4 atDownload user manual for GoPro HERO 4 Black CHDHX-401 HERO4 at
(PDF file, 1.84 MB)
Additional parameters of the GoPro HERO 4 Black CHDHX-401 HERO4 at:
Recording
System NTSC/PAL
Recording Media microSD/HC/XC Up To 64 GB

Class 10 or UHS-1 rating required. See GoPro website for list of latest recommended cards.

Video Format 4K
H.264
3840 x 2160p / 30 fps / 25 fps / 24 fps
High Definition
H.264
2704 x 2028p / 30 fps / 25 fps
High Definition
H.264
2704 x 1520p / 60 fps / 50 fps / 48 fps
High Definition
H.264
2704 x 1520p / 30 fps / 25 fps / 24 fps
High Definition
H.264
1920 x 1440p / 80 fps / 60 fps / 50 fps
High Definition
H.264
1920 x 1440p / 48 fps
High Definition
H.264
1920 x 1440p / 60 fps / 50 fps / 48 fps
High Definition
H.264
1920 x 1440 / 30 fps / 25 fps / 24 fps
High Definition
H.264
1920 x 1080p / 120 fps / 90 fps / 80 fps
High Definition
H.264
1920 x 1080p / 60 fps / 50 fps / 48 fps
High Definition
H.264
1920 x 1080p / 30 fps / 25 fps / 24 fps
High Definition
H.264
1280 x 960p / 120 fps / 60 fps / 50 fps
High Definition
H.264
1280 x 720p / 240 fps / 120 fps / 60 fps
High Definition
H.264
1280 x 720p / 50 fps / 30 fps / 25 fps
Standard Definition
H.264
848 x 480p / 240 fps
Aspect Ratio 16:9
4:3
Still Image Resolution JPEG: 12 Megapixel, 4000 x 3000 (4:3)
JPEG: 7 Megapixel, 3000 x 2250 (4:3)
JPEG: 5 Megapixel, 2560 x 1920 (4:3)
Channels 1.0-Channel Mono

Mono built-in mic; stereo recording possible with separately available external microphone and adapter

Audio Format AAC with AGC
Exposure Control
Interval Recording .5 sec
1 sec
2 sec
5 sec
10 sec
30 sec
60 sec
Features
Waterproof Depth Rating 131.0' / 40.0 m (Waterproof Housing)
Input/Output Connectors
Outputs 1x Mini-USB
1x HDMI D (Micro)

USB port also serves as mic input using separately available 3.5mm adapter. Also supports composite output using a separately available A/V cable.

General
System Requirements Mac
  • OS X 10.8+
  • Core 2 Duo Processor or greater
  • 4 GB RAM

Windows
  • 7
    8
  • Core 2 Duo Processor or greater
  • 4 GB RAM
Battery Rechargeable Lithium-Ion Battery Pack, 3.8 VDC, 1160 mAh,
Providing up to 1.5 Hours per Charge
Charging Method USB
Weight 3.10 oz / 88 g camera only
5.36 oz / 152 g with housing
Packaging Info
Package Weight 1.45 lb
Box Dimensions (LxWxH) 10.1 x 4.3 x 4.1"
The user manual for the GoPro HERO 4 Black CHDHX-401 HERO4 at can be downloaded in .pdf format if it did not come with your new sports & action cameras, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other GoPro users keep a unique electronic library for GoPro sports & action camerass, where you can use our link to download the user manual for the GoPro HERO 4 Black CHDHX-401 HERO4 at.

The user manual lists all of the functions of the GoPro HERO 4 Black CHDHX-401 HERO4 at, all the basic and advanced features and tells you how to use the sports & action cameras. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from GoPro service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the GoPro HERO 4 Black CHDHX-401 HERO4 at. User manuals are also available on the GoPro website under Camcorders - Sports & Action Cameras.
