User manual for the Honeywell Genesis Series 18 AWG RG6/U DUAL-Shielded 5003-11-08
The user manual for the Honeywell Genesis Series 18 AWG RG6/U DUAL-Shielded 5003-11-08 provides
necessary instructions for the proper use of the product Pro Audio - Installation Sound - Bulk Cable.
The 1000' long black Genesis Series 18 AWG RG59/U DUAL-Shielded Broadband Coaxial Cable from Honeywell comes packaged in a pull box. It is a broadband and digital coaxial cable, tested for high standards to assure good performance in high-end home theater installations, incorporating HDTV and digital video. The cable has a foil shielding that protects signal transmission from EMI and RFI interference and blocks lower frequency interference.
