The X4 Pro High Edition Quadcopter with 1080p Camera and 3-Axis Gimbal from Hubsan can - fully laden with gimbal and camera - boasts an expected flight time of up to 27 minutes, depending on conditions. Additionally, with all cargo removed (including camera and gimbal) flights of up to 40 minutes become possible. This bundle is classed ready-to-fly (RTF), meaning all essential hardware is included and only basic assembly - such as attaching the props with the included prop wrench - is required. The bundle includes the H7000, 2.4 GHz smart transmitter (handheld controller) with 7", 1280 x 720p resolution touchscreen and 5.8 GHz video receiver. Not only does it provide dual sticks for flying like a conventions RC transmitter; the touchscreen provides access to the ground station software plus real-time FPV monitoring of a standard definition video feed supplied by a transmitter on the aircraft.

As with other multi-rotor systems, it features a GPS based flight control system. The enables very precise positioning, which is especially important when recording video, and provides enhanced flight stability compared to relying on gyro/IMU data alone. Thanks to the ground station system integrated into the transmitter, waypoint navigation is also possible. With this technology, you simply plot a point-to-point rout over a map using the device's touchscreen. If you change your mind, the waypoint course can be updated in-flight.

Along with the quadcopter, transmitter, gimbal system, and camera, this bundle includes a 7000mAh 3S LiPo flight battery, a 5000mAh LiPo transmitter battery, battery chargers for the flight battery and transmitter battery, a sun shade for the FPV screen, a strap for the transmitter, a prop wrench, a set of prop guards, and antennas for the transmitter and video receiver.
