User manual for the Humminbird Helix 5 SI GPS KVD Fishfinder 409640-1KVD
The user manual for the Humminbird Helix 5 SI GPS KVD Fishfinder 409640-1KVD provides
necessary instructions for the proper use of the product Optics - Outdoor Gear - Fishing & Marine Technology.
Catch more fish on your next salt or freshwater outing thanks to the sonar capabilities of Humminbird's Helix 5 SI GPS KVD. This fishfinder utilizes Side Imaging/Down Imaging KVD, that is filtered with SwitchFire technology. The latter allows you to adjust the sensitivity to fine tune the returns that show on the 5" LED-backlit display. This system has a RMS power output of 500W, and a peak to peak output of 4000W, which allows the unit to provide an accurate representation of the bottom down to 1500' (2D) & 100' (SI). The transom-mounted transducer features multiple coverage angles of 20, 60 & (2) 85° @ -10db (Total of 180°), so that you can adjust the coverage to suit depth and angling conditions for the best returns.
With an internal GPS antenna, you will always know where you are and how fast you are going. Mark waypoints for structures or areas where you've had angling success and return to them at a later date. Built-in UniMap cartography covers the contiguous US coastline, inland lakes and rivers at 30 meters per pixel resolution. Load optional cartography using the micro SD card slot for access to higher resolution maps of waterways across North America.
Also included are 3 of professional BASS Tour angler Kevin VanDam's favorite lures. These are 1 deep-diving crankbait, 1 KVD spinner bait, and a football ledge jig.
|
If you own a Humminbird fishing & marine technology and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Humminbird Helix 5 SI GPS KVD Fishfinder 409640-1KVD in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
|
Additional parameters of the Humminbird Helix 5 SI GPS KVD Fishfinder 409640-1KVD:
| Display Size (Diagonal) | 5" / 12.7 cm | | Display Size | 800 x 480 | | Display Type | Color TFT | | Display Colors | 256 | | Sonar | Sonar Standard: Side Imaging/Down Imaging KVD
Sonar Coverage: 20, 60 & (2) 85° @ -10db (Total of 180°)
Sonar Frequency: 200/83/455 kHz | | Depth | 1500' (2D) & 100' (SI) | | Power Output | Peak to Peak 4000W
RMS 500W | | Cable Length | Transducer cable 20' / 6.1 m | | Transducer Mount | Transom | | Temperature Sensor | Yes, on transducer | | GPS Support | Built-in | | GPS Tracking | Yes | | GPS Logger | Yes | | Stored Waypoints | 2500 | | Stored Routes | 45 | | Tracks/Points | 50/20000 | | Card Slot | 1 x microSD | | Power Draw | 615 mA | | Power Input | 10 to 20 VDC | | Dimension | 7.6 x 4.6 x 3.3" / 19.3 x 11.7 x 8.4 cm | | Weight | Not specified by the manufacturer | | Package Weight | 4.55 lb | | Box Dimensions (LxWxH) | 15.5 x 9.6 x 4.8" | |
