The Ikegami HLM-1705WR 17-Inch HDTV/SDTV Multi-Format LCD Monitor with 2 x SD/HD/3G-SDI & 1 x Composite Input features HD resolution of 1920 x 1080, and supports two channels of SD/HD/3G-SDI inputs, as well as analog composite video signals. The monitor incorporates image tools that allow you to examine the video signal on a technical basis. These tools include waveform, vectorscope, and VITC (Vertical Interval Timecode) displays.

The Ikegami LCD monitor features both in-monitor display, which acts as picture in picture for the diagnostic displays, and under-monitor display, which pushes the secondary display info under the main image. With pixel-by-pixel monitoring mode, the monitor can display your video without any scaling, providing a true representation of your signal.
