User manual Ikegami IK-H3Z4512CSIR 1/2" Varifocal IR IK-H3Z4512CSIR

Operating instructions and pdf manual for use - Ikegami IK-H3Z4512CSIR 1/2" Varifocal IR IK-H3Z4512CSIR User manual, User manual Ikegami IK-H3Z4512CSIR 1/2" Varifocal IR IK-H3Z4512CSIR, Ikegami, IK-H3Z4512CSIR, 1/2, Varifocal, IR, IK-H3Z4512CSIR,


User manual for Ikegami IK-H3Z4512CSIR 1/2" Varifocal IR IK-H3Z4512CSIR

Ikegami IK-H3Z4512CSIR 1/2
  • Manufacturer: Ikegami
  • Basic description and contents of package
  • Product classification: Surveillance - Surveillance Video - Lenses - Lenses
  • Safety instructions
  • Startup and operation of the lenses
  • Tips for setting up your Ikegami
  • Settings and expert assistance
  • Contact Ikegami service
  • Troubleshooting
  • Warranty information
  • Price: 143 USD
We recommend checking out our discussion threads on the Ikegami IK-H3Z4512CSIR 1/2" Varifocal IR IK-H3Z4512CSIR, which address similar problems with connecting and setting up Lenses Ikegami.



User manual for the Ikegami IK-H3Z4512CSIR 1/2" Varifocal IR IK-H3Z4512CSIR

The user manual for the Ikegami IK-H3Z4512CSIR 1/2" Varifocal IR IK-H3Z4512CSIR provides necessary instructions for the proper use of the product Surveillance - Surveillance Video - Lenses - Lenses.

The Ikegami IK-H3Z4512CSIR Varifocal IR Manual Iris Lens (4.5 to 12.5mm) from computar is designed for use with day/night cameras. It eliminates focus shift in night mode, especially in the presence of IR lighting.

The lens is CS-mount, comprises of all glass optics, and comes with locking set screws and a durable metal barrel and mount.
If you own a Ikegami lenses and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Ikegami IK-H3Z4512CSIR 1/2" Varifocal IR IK-H3Z4512CSIR in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Ikegami IK-H3Z4512CSIR 1/2" Varifocal IR IK-H3Z4512CSIR:
Specifications
    Focal Length 4.5 to 12.5 mm
    Maximum Aperture Ratio 1:1.2
    Image Format Maximum: 6.4 x 4.8 mm (Φ8 mm)
    Operation Range Iris: F1.2 to 16C
    Focus: 0.3 m to infinity
    Zoom: 4.5 to 12.5 mm
    Control Iris: Manual
    Focus: Manual
    Zoom: Manual
    Object Dimensions at M.O.D. 4.5 mm: 21.14 x 14.01" (53.7 x 35.6 cm)
    12.5 mm: 6.33 x 4.72" (16.1 x 12 cm)
    Angle of View D: 108.0 to 37.6°
    H: 83.7 to 30.1°
    V: 61.3 to 22.6°
    Operating Temperature -4 to 122°F (-20 to 50°C)
    Effective Lens Aperture Front: Φ19.9 mm
    Rear: Φ9.9 mm
    Back Focal Length Tele: 16.5 mm
    Wide: 8.5 mm
    Flange Back Length 12.5 mm
    Mount Type CS
    Filter Size M35.5 P = 0.5 mm
    Dimensions Φ1.63 x 1.92" (Φ41.6 x 48.8 mm)
    Weight 2.32 oz (66 g)
    Packaging Info
    Package Weight 1.0 lb
    Box Dimensions (LxWxH) 7.0 x 6.0 x 6.0"
    The user manual for the Ikegami IK-H3Z4512CSIR 1/2" Varifocal IR IK-H3Z4512CSIR can be downloaded in .pdf format if it did not come with your new lenses, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Ikegami users keep a unique electronic library for Ikegami lensess, where you can use our link to download the user manual for the Ikegami IK-H3Z4512CSIR 1/2" Varifocal IR IK-H3Z4512CSIR.

    The user manual lists all of the functions of the Ikegami IK-H3Z4512CSIR 1/2" Varifocal IR IK-H3Z4512CSIR, all the basic and advanced features and tells you how to use the lenses. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Ikegami service.

    If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Ikegami IK-H3Z4512CSIR 1/2" Varifocal IR IK-H3Z4512CSIR. User manuals are also available on the Ikegami website under Surveillance - Surveillance Video - Lenses - Lenses.
