User manual Intel 400GB 750 Series 2.5" PCIe 3.0 x4 NVM SSDPE2MW400G4R5
Operating instructions and pdf manual for use - Intel 400GB 750 Series 2.5" PCIe 3.0 x4 NVM SSDPE2MW400G4R5 User manual, User manual Intel 400GB 750 Series 2.5" PCIe 3.0 x4 NVM SSDPE2MW400G4R5, Intel, 400GB, 750, Series, 2.5, PCIe, 3.0, x4, NVM, SS
User manual for Intel 400GB 750 Series 2.5" PCIe 3.0 x4 NVM SSDPE2MW400G4R5
We recommend checking out our discussion threads on the Intel 400GB 750 Series 2.5" PCIe 3.0 x4 NVM SSDPE2MW400G4R5,
which address similar problems with connecting and setting up Internal Drives Intel.
User manual for the Intel 400GB 750 Series 2.5" PCIe 3.0 x4 NVM SSDPE2MW400G4R5
The user manual for the Intel 400GB 750 Series 2.5" PCIe 3.0 x4 NVM SSDPE2MW400G4R5 provides
necessary instructions for the proper use of the product Computers & Solutions - Drives & Storage - Internal Drives.
The 400GB 750 Series 2.5" PCIe 3.0 x4 NVM Express SSD from Intel allows you to store and quickly access up to 400GB of your files, be it movies, music, documents, and much more. With solid state drive technology and a PCI Express Gen3 x4 interface, you benefit from load and access times for your files and programs that are not only faster than a conventional hard disk drive, but also faster than an SSD that uses a SATA connection. This 750 Series SSD is built with a 2.5" / 15mm form factor, providing a cabled solution where an accessible PCIe 3.0 slot is not available and the motherboard has been provisioned with an SFF-8643 connector. This solution is well suited for small form factor and multi-GPU systems where space is an issue. This flexibility also provides a viable direct attach solution for small form designs with an SFF-8639 connector on board.
In terms of speed, this drive offers sequential read times of up to 2,200 MB/s and sequential write times of up to 900 MB/s, as well as 4KB reads up to 430,000 IOPS and 4K writes up to 230,000 IOPS (Input/Output Operations per Second). In addition, this SSD also utilizes 20nm Intel NAND Flash Memory Multi-Level Cell (MLC) flash memory and features a 20 µs read and write latency, 1.2 million hour MTBF, and a lifetime endurance of up to 70GB writes per day. Since SSDs contain no mechanical parts, they are more durable against physical damage, including data loss and are not subject to the wear and tear that standard HDDs receive from read/write heads. It does not any legacy AHCI commands.
If you own a Intel internal drives and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Intel 400GB 750 Series 2.5" PCIe 3.0 x4 NVM SSDPE2MW400G4R5 in the following formats:
*.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Intel 400GB 750 Series 2.5" PCIe 3.0 x4 NVM SSDPE2MW400G4R5:
1.2 million hours Mean Time Between Failures (MTBF)
Lifetime Endurance
70 GB writes per day
Power Consumption
Active Read: 9 W Active Write: 12 W Idle: 4 W
Operating Temperature
32 to 158°F / 0 to 70°C
RoHS Compliance
Meets the requirements of European Union (EU) RoHS Compliance Directives
Product Health Monitoring
Self-Monitoring, Analysis, and Reporting Technology (S.M.A.R.T.) commands
The user manual for the Intel 400GB 750 Series 2.5" PCIe 3.0 x4 NVM SSDPE2MW400G4R5 can be downloaded in .pdf
format if it did not come with your new internal drives, although the seller is
required to supply one. It is also quite common that customers throw out
the user manual with the box, or put the CD away somewhere and then can’t find it.
That’s why we and other Intel users keep a unique electronic library
for Intel internal drivess,
where you can use our link to download the user manual for the Intel 400GB 750 Series 2.5" PCIe 3.0 x4 NVM SSDPE2MW400G4R5.
The user manual lists all of the functions of the Intel 400GB 750 Series 2.5" PCIe 3.0 x4 NVM SSDPE2MW400G4R5,
all the basic and advanced features and tells you how to use the internal drives.
The manual also provides troubleshooting for common problems. Even greater
detail is provided by the service manual, which is not typically shipped with the product,
but which can often be downloaded from Intel service.
If you want to help expand our database, you can upload a link to this website
to download a user manual or service manual, ideally in .pdf format. These pages
are created by you – users of the Intel 400GB 750 Series 2.5" PCIe 3.0 x4 NVM SSDPE2MW400G4R5. User manuals are also
available on the Intel website under Computers & Solutions - Drives & Storage - Internal Drives.
