User manual for the Interlogix UltraView PTZ 27x Standard Dome Camera UVP-CE3-D27N
The user manual for the Interlogix UltraView PTZ 27x Standard Dome Camera UVP-CE3-D27N provides
necessary instructions for the proper use of the product Surveillance - Surveillance Video - Wired Analog & HD Cameras.
The General Electric UltraView PTZ 27x Standard Dome Camera (Wall Mount, Clear Bubble), with a 1/4" CCD image sensor and a 3.25mm (wide) to 88mm (tele) lens, deliver high-quality images at a resolution up to 540 TVL. A minimum illumination of 0.01 lux at 1/4 sec makes the camera suitable for low-light surveillance. The Standard Dome Camera has multiple thresholds and also includes a day/night light sensor that controls day/night mode.
Featured WDR (Wide Dynamic Range) technology enables you to generate real-time images by combining the bright and dark portion of the image and makes it suitable for use in high-contrast areas. The 27x dome camera features an auto slow shutter that slows down the shutter speed, ensuring clear images in dark areas.
With the ability to preset up to 128 positions repeatable to within ±0.1°, the PTZ Dome Camera allows you to set areas, privacy masks, preset, and shadow tours for maximum surveillance. Quick spin feature helps the camera to spin automatically when the bottom of tilt travel is reached. You can also track the motion directly under a camera without losing the picture. Integrated Site-tied memory enables camera replacement without reprogramming.
If you own a Interlogix wired analog & hd cameras and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Interlogix UltraView PTZ 27x Standard Dome Camera UVP-CE3-D27N in the following formats:
*.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Interlogix UltraView PTZ 27x Standard Dome Camera UVP-CE3-D27N:
Specifications
Image Sensor
1/4" CCD
Zoom
Optical 27x; Digital 12x
Resolution
540 TVL
Synchronization
Internal/line lock
Lens
3.25 mm (wide) to 88 mm (tele); F1.5 - 3.8
Sensitivity
0.6 lux at 1/60 sec NTSC or 1/50 sec PAL
Sensitivity, ICR-off0.01 lux at 1/4 sec NTSC or 1/3 sec PAL
Electronic Shutter Speed
1/60 to 1/90,000 sec, NTSC; 1/50 to 1/90,000 sec, PAL
Video Output
1.0 V p-p
General
Manual pan speed: 0.5 to 200°/sec Manual tilt speed: 0.5 to 120°/sec Max. pan/tilt speed: 340°/sec Presets: 128 with 24-character title Preset tours: 4 tours with 64 presets each Shadow tours: 4 with 5 min. each Protocols: Digiplex RS422, Impac RS485, ASCII RS422, Pelco D, Pelco P, Pelco Coaxitron, Ultrak, AD 4800, AD Manchester, BBV, Bosch Biphase, Bosch RS232, KD6,Panasonic, VCL, Vicon
Bubble
Clear acrylic
Regulatory
FCC, CE, C-Tick, UL, RoHS
Operating Temperature
Without heater: 32 to 140° F (0 to 60° C) With heater: -40 to 140° F (-40 to 60° C)
Housing
Wall Mount Housing Electrical Operating voltage: 24 VAC +/- 4 VAC Power: 25 W startup; 20 W running Power, with heater: 93 W startup; 45 W running
Mechanical Environmental enclosure: Rated IP66 Dimensions: 9.5 x 9.6" (241 x 243 mm) Construction: Gray ABS plastic Weight (housing, heater, PTZ): 8 lb (3.87 kg)
