User manual for the IPConfigure Orchid VMS 16-Camera License and IPC-ORC16-TCB2

The user manual for the IPConfigure Orchid VMS 16-Camera License and IPC-ORC16-TCB2 provides necessary instructions for the proper use of the product Surveillance - Surveillance Video - Network Video Recorders (NVRs).

View and manage a medium-sized video surveillance system with the Orchid VMS 16-Camera License and Workstation with Intel i7 Processor from IP Configure. The bundle contains licenses for up to 16 cameras and an NVR with an Intel i7 processor and 8TB of hard drive storage. Use Chrome, Safari, IE, Firefox, or Opera browsers to access the management software, so you can control the system from a wide range of locations. The VMS is compatible with Windows, Windows Server, and Linux server operating systems, as well as Android, iOS, Linux, Windows, and OS X client operating systems.

Orchid software supports an unlimited number of cameras as well as unlimited camera resolution and frame rates. Both MJPEG and H.264 video compressions are supported, and the software uses MKV formatting when exporting information. Motion detection, digital and optical PTZ, and simultaneous live and recorded playback features allow for comprehensive data analysis. A timeline bar with motion-event search helps you easily navigate your saved footage, and unlimited user accounts with fixed roles enable multiple secure viewing options. The software is ONVIF-compliant for compatibility with over 2500 cameras and encoders.

With 8GB of RAM and an Intel i7 processor, the NVR can accommodate most high-resolution cameras. Dual Gigabit Ethernet ports enable simultaneously connection to more than one network, and the included hard drive is surveillance-grade for high-quality performance and long-lasting storage. The NVR is pre-loaded with the Ubuntu Linux 14.04 LTS operating system and can also support Windows 7 Professional and Windows Server operating systems. The package also includes a 19" viewing monitor, a keyboard, and a mouse.
If you own a IPConfigure network video recorders (nvrs) and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the IPConfigure Orchid VMS 16-Camera License and IPC-ORC16-TCB2 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the IPConfigure Orchid VMS 16-Camera License and IPC-ORC16-TCB2:
VMS Specifications
Number of Licenses 16
Supported Browsers Chrome, Safari, IE, Firefox, Opera
Server Operating System Linux, Windows, Windows Server
Client Operating System Android, iOS, Linux, Windows, OS X
Hardware Platform x86_64, ARM, MIPS
Language English, extendable via SDK
Video Compression MJPEG, H.264
Camera Resolution Unlimited
Camera Frame Rate Unlimited
Cameras Supported Unlimited (with additional licenses, available separately)
32 recommended
Compatibility ONVIF Profile S
Security Unlimited user accounts with fixed roles
PTZ Digital and optical
Search Analysis Timeline bar with motion events
Playback Simultaneous live and recorded
Export Format MKV
Motion Detection Yes
Recording Continuous, motion-only, motion variable frame rate
Reports Health and troubleshooting
Open API Orchid web service
NVR Specifications
Processor Intel i7
Memory 8 GB
Video Card AMD Radeon HD 6450
RAID None
Total Storage 2 x 4 TB (8 TB usable)
Operating System Ubuntu Linux 14.04 LTS
OS Drive 120 GB SSD
Network Ports 2 x Gigabit Ethernet
Dimensions 12.2 x 7.8 x 10.6" / 31.0 x 19.8 x 26.9 cm
Weight 19.0 lb / 8.6 kg
The user manual for the IPConfigure Orchid VMS 16-Camera License and IPC-ORC16-TCB2 can be downloaded in .pdf format if it did not come with your new network video recorders (nvrs), although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other IPConfigure users keep a unique electronic library for IPConfigure network video recorders (nvrs)s, where you can use our link to download the user manual for the IPConfigure Orchid VMS 16-Camera License and IPC-ORC16-TCB2.

The user manual lists all of the functions of the IPConfigure Orchid VMS 16-Camera License and IPC-ORC16-TCB2, all the basic and advanced features and tells you how to use the network video recorders (nvrs). The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from IPConfigure service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the IPConfigure Orchid VMS 16-Camera License and IPC-ORC16-TCB2. User manuals are also available on the IPConfigure website under Surveillance - Surveillance Video - Network Video Recorders (NVRs).
