The white AM5215/95 2-Way Loudspeaker System with 1 x 15" LF Speaker from JBL is comprised of the JBL Differential Drive, dual voice coil and dual magnetic gap 265H-1 (15") low frequency driver, and 2408H-1 high frequency 1.5" exit, 1.5" voice-coil compression driver. The large format PT Progressive Transition waveguide provides a 90° x 50° coverage. The waveguide is rotatable so the loudspeaker system can be used in either the vertical or horizontal orientation. High-slope passive networks minimize band overlap. Well-controlled off-axis response enhances arrayability.

The AM5215/95 will perform as either a bi-amped or passive cabinet, at the flick of a switch, making it versatile for many sound amplification applications, such as: performing arts facilities,theatrical sound design, auditoriums, worship facilities, live clubs, dance clubs, sports facilities, and themed entertainment venues.
If you own a JBL pa speakers and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the JBL AM5215/95 2-Way Loudspeaker System with 1 x 15 AM5215/95-WH in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the JBL AM5215/95 2-Way Loudspeaker System with 1 x 15 AM5215/95-WH:
Active or Passive Passive
Low Frequency Driver 1 x JBL 265H-1 15" (381 mm) driver with 2" (50.8 mm) dual voice coil
Nominal Impedance: 8 ohms
Sensitivity: 99 dB SPL (1W @ 1m, within operational band)
High Frequency Driver JBL 2408H-1, 1.5" (38 mm ) exit compression driver, 1.5" (38 mm ) voice coil
Nominal Impedance: 8 ohms
Sensitivity: 113 dB SPL (1W @ 1m)
Frequency Range 35 Hz to 20 kHz (-10 dB)
Frequency Response ± 3dB 41 Hz to 18 kHz
Coverage Pattern 90° x 50°
Coverage Modes Bi-amp / Passive switchable
Directivity Factor 11.6 dB (Q)
Directivity Index 10.6 dB
Crossover Point 1.8 kHz (Passive)
Transducer Power Rating 500 W (2000 W peak), 2 hrs
350 W (1400 W peak). 100 hrs
HF: 40 W (160 W peak), 2 hrs
Long-Term System Power Rating 350 W (1400 W peak) 100 hrs (IEC)
Maximum SPL Bi-amp Mode:
LF: 125 dB-SPL cont avg (128 dB peak)
HF: 129 dB-SPL cont avg (135 dB peak)
System Sensitivity Passive mode: 98 dB SPL (1W @ 1m)
Horn Waveguide PT-H95HF-1
Enclosure Material Trapezoidal with 15 degree side angles, 5/8" (16 mm) exterior grade 11-ply birch plywood
Suspension Attachment 15 points (4 top, 4 bottom, 2 each side, 3 rear), M10 threaded hardware
Finish White DuraFlex finish
Grille Powder coated 14 gauge perforated steel, with acoustically transparent black foam backing
Environmental Specifcations Mil-Std 810; IP-x3 per IEC529
Dimensions 30.8 x 16.6 x 19.85" (83 x 422 x 504 mm)
Weight 55 lb (25 kg)
Packaging Info
Package Weight 60.0 lb
Box Dimensions (LxWxH) 32.5 x 21.0 x 17.75"
