User manual Kingston 120GB KC300 SSDNow SATA III 2.5" SKC300S37A/120G

Operating instructions and pdf manual for use - Kingston 120GB KC300 SSDNow SATA III 2.5" SKC300S37A/120G User manual, User manual Kingston 120GB KC300 SSDNow SATA III 2.5" SKC300S37A/120G, Kingston, 120GB, KC300, SSDNow, SATA, III, 2.5, SKC300S37A


User manual for Kingston 120GB KC300 SSDNow SATA III 2.5" SKC300S37A/120G

Kingston 120GB KC300 SSDNow SATA III 2.5
  • Manufacturer: Kingston
  • Basic description and contents of package
  • Product classification: Computers & Solutions - Drives & Storage - Internal Drives
  • Safety instructions
  • Startup and operation of the internal drives
  • Tips for setting up your Kingston
  • Settings and expert assistance
  • Contact Kingston service
  • Troubleshooting
  • Warranty information
  • Price: 70 USD
Kingston 120GB KC300 SSDNow SATA III 2.5 Kingston 120GB KC300 SSDNow SATA III 2.5 Kingston 120GB KC300 SSDNow SATA III 2.5 Kingston 120GB KC300 SSDNow SATA III 2.5 Kingston 120GB KC300 SSDNow SATA III 2.5
Click to enlarge image

We recommend checking out our discussion threads on the Kingston 120GB KC300 SSDNow SATA III 2.5" SKC300S37A/120G, which address similar problems with connecting and setting up Internal Drives Kingston.



User manual for the Kingston 120GB KC300 SSDNow SATA III 2.5" SKC300S37A/120G

The user manual for the Kingston 120GB KC300 SSDNow SATA III 2.5" SKC300S37A/120G provides necessary instructions for the proper use of the product Computers & Solutions - Drives & Storage - Internal Drives.

Designed with a SandForce SF2281 controller, the 120GB KC300 SSDNow SATA III 2.5" Internal SSD from Kingston features a 120GB storage capacity, allowing you to store a variety of files including movies, photos, music, and more. This SSD connects to your system's 2.5" / 7mm bay via the SATA III 6 Gb/s interface. With solid-state drive technology, you benefit from load and access times for your files and programs that are faster than a conventional hard disk drive. Enhanced data read speeds of up to 525 MB/s and data write speeds of up to 500 MB/s allow you to access data stored within the drive quickly and efficiently. Additionally, this drive features 4K reads up to 85,000 IOPS, 4K writes up to 64,000 IOPS, random 4K reads up to 17,000 IOPS, and random 4K writes up to 64,000 IOPS (Input/Output Operations per Second).

Along with enhanced performance, you benefit from Enterprise SMART tools, which includes reliability tracking, usage statistics, life remaining, wear leveling, and temperature monitoring. Integrated DuraClass Technology is a set of NAND flash management features that work together to deliver enhanced SSD endurance, reliability, performance and power efficiency.

With DuraClass you benefit from a variety of features including DuraWrite and RAISE, along with advanced wear leveling. This drive also supports AES 256-bit encryption, TCG Opal 2.0, and IEEE 1667 to help further enhance the drive's security. The KC300 features a Physical Security ID (PSID) printed on the drive label which allows users to revert a managed drive back to the factory default. It is protected by a limited 3-year warranty with free technical support.
If you own a Kingston internal drives and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Kingston 120GB KC300 SSDNow SATA III 2.5" SKC300S37A/120G in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
User manual for Kingston 120GB KC300 SSDNow SATA III 2.5Download user manual for Kingston 120GB KC300 SSDNow SATA III 2.5" SKC300S37A/120G
(PDF file, 1.43 MB)
Additional parameters of the Kingston 120GB KC300 SSDNow SATA III 2.5" SKC300S37A/120G:
Specifications
    Form Factor 2.5"
    Interface SATA III 6 Gb/s with backwards compatibility to SATA II 3 Gb/s
    Capacity 120 GB
    Controller SandForce-SF2281
    Encryption Automatic AES 256-bit Encryption
    Sequential Read Speed SATA III 6 Gb/s: up to 525 MB/s
    Sequential Write Speed SATA III 6 Gb/s: up to 500 MB/s
    Maximum 4K Read Up to 85,000 IOPS
    Maximum 4K Write Up to 64,000 IOPS
    Random 4K Read up to 17,000 IOPS
    Random 4K Write 64,000 IOPS
    Total Bytes Written (TBW) 290 TB 2 Drive Writes per Day (DWPD)
    Power Consumption Idle: 0.08 W
    Average: 0.16 W
    Read: 1.73 W (max)
    Write: 2.49 W (max)
    Storage Temperature -40 to 185°F / -40 to 85°C
    Operating Temperature 32 to 158°F / 0 to 70°C
    Vibration Operating: 2.17 G Peak (7 to 800 Hz)
    Non-Operating: 20 G Peak (10 to 2,000 Hz)
    MTBF 1 million hours
    Dimensions 2.7 x 3.9 x 0.2" / 69.8 x 100.1 x 7.0 mm
    Weight 3.03 oz / 86.00 g
    Packaging Info
    Package Weight 0.3 lb
    Box Dimensions (LxWxH) 7.0 x 3.6 x 0.4"
    The user manual for the Kingston 120GB KC300 SSDNow SATA III 2.5" SKC300S37A/120G can be downloaded in .pdf format if it did not come with your new internal drives, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Kingston users keep a unique electronic library for Kingston internal drivess, where you can use our link to download the user manual for the Kingston 120GB KC300 SSDNow SATA III 2.5" SKC300S37A/120G.

    The user manual lists all of the functions of the Kingston 120GB KC300 SSDNow SATA III 2.5" SKC300S37A/120G, all the basic and advanced features and tells you how to use the internal drives. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Kingston service.

    If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Kingston 120GB KC300 SSDNow SATA III 2.5" SKC300S37A/120G. User manuals are also available on the Kingston website under Computers & Solutions - Drives & Storage - Internal Drives.
