The DR from Lectrosonics is a modular 256-bit encrypted six-channel digital wireless receiver and host mainframe for use with the DSW Encrypted Digital Wireless System that includes DSP, microprocessor, antenna multicoupler, and control interface. It can be used when receiver modules (sold separately) are installed on either side of the mainframe for audio applications such as broadcast TV, live stage, theater, houses of worship, and more. The frequency response is 20 Hz to 20 kHz. The digital architecture, which operates on the standard UHF FCC part 74 frequencies (TV channel band), provides only 2.5 ms of latency and has a better, extended operating range than standard analog and Digital Hybrid Wireless systems.
If you own a Lectrosonics wireless receivers and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Lectrosonics DR - Encrypted Receiver (470.100 to 691.175 MHz) DR in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Lectrosonics DR - Encrypted Receiver (470.100 to 691.175 MHz) DR:
System
Operating Frequencies 470.100 - 691.175 MHz in 25 kHz steps
Sampling Size and Rate 24-bit, 48 kHz
Modulation Digital: 8PSK
Symbol Rate 128 k
Data Compression Method Proprietary ADPCM
Encryption AES 256-CTR (per FIPS 197 and FIPS 140-2)
System Latency 2.5 ms
Audio Frequency Response 20 Hz to 20 kHz, +/- 1 dB
Distortion 0.05% THD+N, 1 kHz @ -10 dBFS
Dynamic Range 108 dB A-wtd, NR=normal
Receiver
Sensitivity -98 dBm for 10-5 BER
Diversity Method Noiseless antenna switching
Antenna Inputs 2x BNC female, 50 ohms impedance
Audio Outputs 6x XLR balanced, -50 to +5 dBU analog or 3x AES-EBU
Headphone 1/4" (6.3 mm) phone jack
External DC Source 10 to 18 VDC; 40 Watts fully populated
Dimensions (L x H x D) 19 x 1.75 x 10.6" (483 x 44 x 269 mm)
Weight 6.58 lb (2.98 kg)
The user manual for the Lectrosonics DR - Encrypted Receiver (470.100 to 691.175 MHz) DR can be downloaded in .pdf format if it did not come with your new wireless receivers, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Lectrosonics users keep a unique electronic library for Lectrosonics wireless receiverss, where you can use our link to download the user manual for the Lectrosonics DR - Encrypted Receiver (470.100 to 691.175 MHz) DR.

The user manual lists all of the functions of the Lectrosonics DR - Encrypted Receiver (470.100 to 691.175 MHz) DR, all the basic and advanced features and tells you how to use the wireless receivers. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Lectrosonics service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Lectrosonics DR - Encrypted Receiver (470.100 to 691.175 MHz) DR. User manuals are also available on the Lectrosonics website under Pro Audio - Location Sound - Wireless Receivers.
