Designed for fixed installation, the Lectrosonics R400A receiver is a half-rack unit featuring Lectrosonic's digital hybrid technology. The dual antennas are an affirmation to it's Smart Diversity enhanced reception circuitry. The rear panel features both XLR and 1/4" phone output connections, both with output level control adjust. A comprehensive LCD displays pilot tone, antenna phase, transmitter battery status, audio level, RF level, battery timer, frequency, and transmitter switch settings.
If you own a Lectrosonics wireless receivers and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Lectrosonics R400A UHF Diversity Receiver (22) R400A-22 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Lectrosonics R400A UHF Diversity Receiver (22) R400A-22:
Type of Receiver R400
RF Carrier Frequency Range Block 22: TV Channels 29 to 33 (563.200 to 588.700MHz)
Approx. Working Range not specified by manufacturer
Overall Frequency Response 30Hz to 20kHz (+/- 1dB)
Signal-to-Noise Ratio @ receiver output (dB)-
SmartNR Off: 103.5dB
SmartNR Normal: 107dB
SmartNR Full: 108.5dB
# Of Channels 256 User Selectable UHF Frequencies
Type of Output(s) Balanced: 3-pin XLR
Unbalanced: 1/4" Phone
Headphone Monitoring No
Power Requirements Minimum 8 volts to maximum 18 volts DC; 1.6 W, 200mA maximum
Battery Type/Approx. Life not applicable, DC power only
Display LCD Main Window:
Pilot tone; antenna phase, transmitter battery status, audio level, RF level, battery timer, frequency, and Transmitter switch setting
Mounting Options Optional RMPR400-1 / RMPR400-2, single and dual unit rack mount kits.
Antenna Type Antenna Type
Dimensions 5.50 x 1.75 x 6.25" (14 x 4.5 x 16cm) (WxHxD)
Weight 12.4 oz
Packaging Info
Package Weight 2.15 lb
Box Dimensions (LxWxH) 14.0 x 10.7 x 4.1"
The user manual for the Lectrosonics R400A UHF Diversity Receiver (22) R400A-22 can be downloaded in .pdf format if it did not come with your new wireless receivers, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Lectrosonics users keep a unique electronic library for Lectrosonics wireless receiverss, where you can use our link to download the user manual for the Lectrosonics R400A UHF Diversity Receiver (22) R400A-22.
