The compact DM16 16-Input Analog Live/Studio Mixer from MIDAS provides remarkable sonic performance and amazing versatility. The DM16 Mixer features MIDAS microphone preamplifiers with true +48 phantom power that delivers transparency and nuanced low noise and high-headroom design. The mixer has TRS line inputs on all 16 channels (12 mono and 2 stereo), mono channel inserts and 3-band EQ with mid-frequency sweep, 2 switchable pre/post-fader aux sends, 2 monitor outs, and 2-track RCA I/O.
