User manual for the Newcon Optik NVS-15 Autogated 3rd Gen NVD Binocular NVS 15-3AGBW

The user manual for the Newcon Optik NVS-15 Autogated 3rd Gen NVD Binocular NVS 15-3AGBW provides necessary instructions for the proper use of the product Optics - Night & Thermal Vision - Night Vision Binoculars.

The NVS-15 Autogated 3nd Gen NVD Binocular from Newcon Optik includes a headgear and features two 64 lp/mm high resolution 3rd generation intensifier tubes with GaAs photocathodes. If you are moving through environments with changing infrared lighting conditions and need to adjust brightness of your images, you can use a manual gain control. The optical system features a 27.5mm f/1.17 lens, a 1x magnification, a 40° angular field of view, and a 10" minimum focus. If you are training or conducting a mission in complete darkness with no ambient infrared, you can use a built-in infrared illuminator to illuminate your targets. The included headgear is completely adjustable and connect to this NVD via integrated adapter.

The rugged and durable construction features a housing that can endure extensive temperature ranges and is submersible to 3' for a half an hour. Additionally, the binocular features a modular design, where, the two tubes are completely independent entities that are connected by a bridge. Therefore, they can be disconnected and used independently while mounted to a barrel or as handheld devices. Also included with this NVD are headgear, two AA batteries, lens covers, a carry case, and a lens cleaning kit.
If you own a Newcon Optik night vision binoculars and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Newcon Optik NVS-15 Autogated 3rd Gen NVD Binocular NVS 15-3AGBW in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Newcon Optik NVS-15 Autogated 3rd Gen NVD Binocular NVS 15-3AGBW:
Intensifier Tube Autogated 3rd generation
GaAs photocathode
64 lp/mm
SNR: 24
Magnification 1x
Angle/Field of View Angular: 40° Linear: 210' @ 100 yd (70 @ 100 m)
Lens System f/1.17
Focal length: 27.5 mm
Minimum Focus Distance 10" (0.25 m)
Eye Relief 25 mm
Dioptric Correction -6 to +5
Interpupillary Adjustment 52-74 mm
Infrared Illuminator Built-in illuminator
Battery / Runtime 2 x AA battery / 40 hr max
2 x CR123
Weatherproofing Waterproof to 3' (1 m) for 30 minutes
Operating Temperature -58 to 131°F (-50 to 55°C)
Storage Temperature -58 to 158°F (-50 to 70°C)
Dimensions 4.7 x 4.6 x 2.7" (120 x 118 x 69 mm)
Weight 28.5 oz (725 g) without batteries
The user manual for the Newcon Optik NVS-15 Autogated 3rd Gen NVD Binocular NVS 15-3AGBW can be downloaded in .pdf format if it did not come with your new night vision binoculars, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Newcon Optik users keep a unique electronic library for Newcon Optik night vision binocularss, where you can use our link to download the user manual for the Newcon Optik NVS-15 Autogated 3rd Gen NVD Binocular NVS 15-3AGBW.

The user manual lists all of the functions of the Newcon Optik NVS-15 Autogated 3rd Gen NVD Binocular NVS 15-3AGBW, all the basic and advanced features and tells you how to use the night vision binoculars. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Newcon Optik service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Newcon Optik NVS-15 Autogated 3rd Gen NVD Binocular NVS 15-3AGBW. User manuals are also available on the Newcon Optik website under Optics - Night & Thermal Vision - Night Vision Binoculars.
