User manual for the NewerTech Power2U AC/USB Wall Outlet (15A, Black) NWTPWR2U15ATRK
The user manual for the NewerTech Power2U AC/USB Wall Outlet (15A, Black) NWTPWR2U15ATRK provides
necessary instructions for the proper use of the product A/V Presentation - Cables & Accessories - Floor, Wall & Table Boxes.
The black Power2U 15A AC/USB Wall Outlet from NewerTech is a convenient and energy-efficient in-wall solution for powering and charging USB devices. The wall outlet helps you charge and/or power up to four devices simultaneously when using USB ports and the National Electrical Code (NEC) compliant tamper-resistant AC receptacles, while eliminating unsightly clutter created by multiple cables and bulky power adapters.
If you own a NewerTech floor, wall & table boxes and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the NewerTech Power2U AC/USB Wall Outlet (15A, Black) NWTPWR2U15ATRK in the following formats:
*.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the NewerTech Power2U AC/USB Wall Outlet (15A, Black) NWTPWR2U15ATRK:
Specifications
Electrical
Grounding: Self Amperage: 15 A Voltage: 125 V NEMA: 5-15 R compliant Pole: 2 Wire: 3 Dielectric Voltage: Withstands 2000 V per UL 498 DC Specifications: 5.2 V, 2500 mA (12.5 W) duplex USB charging receptacle with integrated on/off safety switch for USB power HP Ratings: 125 V AC: 58.8 A Current Limiting: Full Rated Current Temperature Rise: Maximum contact temperature rise 81.68°F (27.6°C) Maximum terminal temperature rise 67.64°F (19.8°C)
Environmental
Flammability: Rated V-2 / UL94 Operating Temperature: -40 to 140°F (-40 to 60˚C)
General
Color: Black Face Material: Polycarbonate Body Material: Polycarbonate Line Contacts: Brass Triple-Wipe .031 thick Terminal Screws: Brass 10-32 Grounding Screw: Brass 8-32 Strap Material: Zinc-Plated Steel Clamp Nuts: Zinc-Plated Steel Ground Clips: Brass-Plated
Mechanical
Terminal ID: Brass: Hot Green: Ground Silver: Neutral Terminal Accommodation: 14-10 AWG Termination: Side
The user manual for the NewerTech Power2U AC/USB Wall Outlet (15A, Black) NWTPWR2U15ATRK can be downloaded in .pdf
format if it did not come with your new floor, wall & table boxes, although the seller is
required to supply one. It is also quite common that customers throw out
the user manual with the box, or put the CD away somewhere and then can’t find it.
That’s why we and other NewerTech users keep a unique electronic library
for NewerTech floor, wall & table boxess,
where you can use our link to download the user manual for the NewerTech Power2U AC/USB Wall Outlet (15A, Black) NWTPWR2U15ATRK.
The user manual lists all of the functions of the NewerTech Power2U AC/USB Wall Outlet (15A, Black) NWTPWR2U15ATRK,
all the basic and advanced features and tells you how to use the floor, wall & table boxes.
The manual also provides troubleshooting for common problems. Even greater
detail is provided by the service manual, which is not typically shipped with the product,
but which can often be downloaded from NewerTech service.
If you want to help expand our database, you can upload a link to this website
to download a user manual or service manual, ideally in .pdf format. These pages
are created by you – users of the NewerTech Power2U AC/USB Wall Outlet (15A, Black) NWTPWR2U15ATRK. User manuals are also
available on the NewerTech website under A/V Presentation - Cables & Accessories - Floor, Wall & Table Boxes.
