User manual for Nikon D5300 DSLR Camera with 18-55mm Lens (Black) 1522
Overall Rating: 4.5
90% of respondents would recommend this to a friend.
- Manufacturer: Nikon
- Basic description and contents of package
- Product classification: Photography - Digital Cameras - DSLR Cameras
- Safety instructions
- Startup and operation of the dslr cameras
- Tips for setting up your Nikon
- Settings and expert assistance
- Contact Nikon service
- Troubleshooting
- Warranty information
- Price: 597 USD
Click to enlarge image
|
We recommend checking out our discussion threads on the Nikon D5300 DSLR Camera with 18-55mm Lens (Black) 1522,
which address similar problems with connecting and setting up DSLR Cameras Nikon.
|
User manual for the Nikon D5300 DSLR Camera with 18-55mm Lens (Black) 1522
The user manual for the Nikon D5300 DSLR Camera with 18-55mm Lens (Black) 1522 provides
necessary instructions for the proper use of the product Photography - Digital Cameras - DSLR Cameras.
The black Nikon D5300 DSLR Camera features a DX-format 24.2 megapixel sensor and EXPEED 4 image processor to produce high-resolution still imagery and full HD video with notable low-light sensitivity to ISO 12800 and a fast continuous shooting rate of 5 fps. The sensor design omits the traditional optical low-pass filter in order to gain the utmost sharpness and resolution from both photos and videos. Complementing the imaging assets are both a versatile 39-point autofocus system, with nine cross-type sensors, and a 2,016-pixel RGB sensor for precise exposure metering in a wide variety of lighting conditions. Additionally, 1920 x 1080p movie recording is supported, in multiple frame rates up to 60 fps, with full-time continuous auto focusing capabilities.
The compact, yet durably designed, camera body incorporates both an optical pentamirror optical viewfinder along with a large 3.2" 1,037k-dot vari-angle LCD monitor, which features a 180° swivel design to better support working from high and low angles. Also integrated into the D5300 are both Wi-Fi and GPS modules, which enable advanced image sharing capabilities as well as location-based image tagging. When paired with an Android or iOS mobile device, remote viewing and control over the shutter release is possible from a distance and a vast network of pre-populated Points of Interest adds to the overall geotagging functionality.
For creatively enhancing the look and feel of imagery in-camera, a wide range of Picture Control modes, Scene Modes, and Special Effects modes are available as well as a host of in-camera image editing capabilities for adjusting settings prior to sharing. Built-in HDR and Active D-Lighting modes can also be used to optimize exposure results by preserving highlight and shadow details for an extended range of apparent tones.
Included with the D5300 camera body is the AF-S DX NIKKOR 18-55mm f/3.5-5.6G VR II lens; a standard zoom providing a 35mm-equivalent focal length range of 27-82.5mm. This lens incorporates a robust VR image stabilization system, which helps to minimize the appearance of camera shake by up to four shutter speed steps to benefit working in low-light conditions. A Super Integrated Coating reduces flare and ghosting to optimize image clarity, contrast, and color neutrality and a rounded seven-blade diaphragm works to create a pleasing out-of-focus quality in shallow depth of field images.
|
If you own a Nikon dslr cameras and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Nikon D5300 DSLR Camera with 18-55mm Lens (Black) 1522 in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
|
Additional parameters of the Nikon D5300 DSLR Camera with 18-55mm Lens (Black) 1522:
| Lens Mount | Nikon F | | Camera Format | DX / (1.5x Crop Factor) | | Pixels | Actual: 24.78 Megapixel
Effective: 24.2 Megapixel | | Max Resolution | 24 MP: 6000 x 4000 | | Aspect Ratio | 3:2 | | Sensor Type / Size | CMOS, 23.5 x 15.6 mm | | File Formats | Still Images: JPEG, RAW
Movies: MOV, MPEG-4 AVC/H.264
Audio: Linear PCM | | Bit Depth | 14-bit | | Dust Reduction System | Yes | | Memory Card Type | SD
SDHC
SDXC | | Focus Type | Auto & Manual | | Focus Mode | Continuous-servo AF (C), Manual Focus (M), Single-servo AF (S) | | Autofocus Points | Phase Detection: 39 | | Viewfinder Type | Pentamirror | | Viewfinder Coverage | 95% | | Viewfinder Magnification | Approx. 0.82x | | Diopter Adjustment | - 1.7 to +1 m | | Display Screen | 3.2" Rear Screen Swivel LCD (1,037,000) | | Screen Coverage | 100% | | Diagonal Angle of View | 170.0° | | ISO Sensitivity | Auto, 100-12800 (Extended Mode: 100-25600) | | Shutter | Type: Electronic & Mechanical
Speed: 30 - 1/4000 second, Bulb Mode | | Remote Control | MC-DC2 (Optional) | | Mirror Lock-Up | Yes | | Metering Method | 3D Color Matrix Metering, Center-weighted average metering, Spot metering | | Exposure Modes | Modes: Aperture Priority, Auto, Manual, Programmed Auto, Scene Modes, Shutter Priority
Metering Range: EV 0.0 - EV 20.0
Compensation: -5 EV to +5 EV (in 1/3 or 1/2 EV steps) | | White Balance Modes | Auto, Cloudy, Direct Sunlight, Flash, Fluorescent, Incandescent, Preset Manual, Shade | | Flash Modes | Auto
Auto/Red-eye Reduction
Fill-in
Off
Rear Curtain/Slow Sync
Rear Sync
Red-eye Reduction
Slow Sync
Slow Sync/Red-eye Reduction | | Built-in Flash | Yes | | Guide No. | 42.65' (13 m) ISO100 | | Max Sync Speed | 1 / 200 seconds | | Flash Compensation | -3 EV to +1 EV (in 1/3 or 1/2 EV steps) | | Dedicated Flash System | iTTL | | External Flash Connection | Hot Shoe | | Video Recording | Yes | | File Size | 1920 x 1080p (Full HD)
1280 x 720p (HD)
640 x 424p (SD) | | Aspect Ratio | 16:9 | | Frame Rate | @ 1920 x 1080: 60 fps, 50 fps, 30 fps, 25 fps, 24 fps
@ 1280 x 720: 60 fps, 50 fps
@ 640 x 424: 30 fps, 25 fps | | Exposure Control | Auto
Manual | | Focus | Auto
Manual
Continuous Auto | | Video Clip Length | 1920 x 1080
@ 60 fps: 20 min.
@ 30 fps: 29 min. | | Audio Recording | Built-in Mic: With Video, Stereo
Optional External Mic: With Video | | Continuous Shooting | Up to 5 fps | | Self Timer | 2 seconds, 5 seconds, 10 seconds, 20 seconds
Number of Shots: 1-9 | | Interval Recording | Yes | | Connectivity | 1/8" Microphone, AV Output, HDMI C (Mini), USB 2.0 | | Wi-Fi Capable | Yes | | Battery | 1x EN-EL14a Rechargeable Lithium-ion Battery Pack, 7.2 VDC, 1230 mAh | | AC Power Adapter | EH-5b (Optional) | | Operating/Storage Temperature | Operating
32 to 104°F (0 to 40°C) | | Dimensions (WxHxD) | 4.9 x 3.9 x 3.0" / 125.0 x 98.0 x 76.0 mm | | Weight | 1.06 lb / 480 g body only | | Focal Length | 18 - 55mm
Comparable 35mm Focal Length: 27 - 82.5 mm | | Aperture | Maximum: f/3.5 - 5.6
Minimum: f/22 - 36 | | Angle of View | 76° - 28° 50' | | Minimum Focus Distance | 11.02" (28 cm) | | Magnification | 0.31x | | Elements/Groups | 11/8 | | Diaphragm Blades | 7, Rounded | | Autofocus | Yes | | Image Stabilization | Yes | | Filter Thread | Front:52 mm | | Dimensions (DxL) | Approx. 2.34 x 2.60" (59.5 x 66 mm) | | Weight | 6.88 oz (195 g) | | Package Weight | 3.35 lb | | Box Dimensions (LxWxH) | 8.7 x 6.6 x 5.4" | |
The user manual for the Nikon D5300 DSLR Camera with 18-55mm Lens (Black) 1522 can be downloaded in .pdf
format if it did not come with your new dslr cameras, although the seller is
required to supply one. It is also quite common that customers throw out
the user manual with the box, or put the CD away somewhere and then can’t find it.
That’s why we and other Nikon users keep a unique electronic library
for Nikon dslr camerass,
where you can use our link to download the user manual for the Nikon D5300 DSLR Camera with 18-55mm Lens (Black) 1522.
The user manual lists all of the functions of the Nikon D5300 DSLR Camera with 18-55mm Lens (Black) 1522,
all the basic and advanced features and tells you how to use the dslr cameras.
The manual also provides troubleshooting for common problems. Even greater
detail is provided by the service manual, which is not typically shipped with the product,
but which can often be downloaded from Nikon service.
If you want to help expand our database, you can upload a link to this website
to download a user manual or service manual, ideally in .pdf format. These pages
are created by you – users of the Nikon D5300 DSLR Camera with 18-55mm Lens (Black) 1522. User manuals are also
available on the Nikon website under Photography - Digital Cameras - DSLR Cameras.
