User manual NUOPTIC VIS-1080 Series 80W True Hybrid Varifocal VIS-1080-SH8

Operating instructions and pdf manual for use - NUOPTIC VIS-1080 Series 80W True Hybrid Varifocal VIS-1080-SH8 User manual, User manual NUOPTIC VIS-1080 Series 80W True Hybrid Varifocal VIS-1080-SH8, NUOPTIC, VIS-1080, Series, 80W, True, Hybrid, Va


User manual for NUOPTIC VIS-1080 Series 80W True Hybrid Varifocal VIS-1080-SH8

NUOPTIC VIS-1080 Series 80W True Hybrid Varifocal VIS-1080-SH8
  • Manufacturer: NUOPTIC
  • Basic description and contents of package
  • Product classification: Surveillance - Surveillance Video - Additional Accessories - Illuminators
  • Safety instructions
  • Startup and operation of the illuminators
  • Tips for setting up your NUOPTIC
  • Settings and expert assistance
  • Contact NUOPTIC service
  • Troubleshooting
  • Warranty information
We recommend checking out our discussion threads on the NUOPTIC VIS-1080 Series 80W True Hybrid Varifocal VIS-1080-SH8, which address similar problems with connecting and setting up Illuminators NUOPTIC.



User manual for the NUOPTIC VIS-1080 Series 80W True Hybrid Varifocal VIS-1080-SH8

The user manual for the NUOPTIC VIS-1080 Series 80W True Hybrid Varifocal VIS-1080-SH8 provides necessary instructions for the proper use of the product Surveillance - Surveillance Video - Additional Accessories - Illuminators.

The NUOPTIC VIS-1080 Series 80W True Hybrid Varifocal Illuminator is used with both analog and IP day/night video security cameras and can output both infrared and white light to a maximum distance of 886’ (270 m) and 689’ (210 m), respectively. A varifocal illuminator, it features 850nm, high-efficiency LEDs and uses sophisticated precision, enabling you to adjust its field of illumination and wavelength (white light or infrared) without having to change a single part. Its digital input control also allows the light source to be triggered by an operator or automatically by the camera control.

This illuminator is capable of motorized varifocal zoom and can use covert IR lighting for zero light pollution in low light environments. The unit can also be triggered into White-Light mode to provide color imagery and visible lighting deterrence. It can do both wide and narrow settings, eliminating the need for two separate illuminators.

With up to 64 presets for integration with PTZ applications, this illuminator can store illumination and brightness levels that match the camera’s field of view. In addition, its field of illumination can be set to match the setting of the camera lens.

Installation is facilitated by control knobs located inside the unit’s environmental cover or by using the RS-232, RS-485, or Pelco D interfaces.
If you own a NUOPTIC illuminators and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the NUOPTIC VIS-1080 Series 80W True Hybrid Varifocal VIS-1080-SH8 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the NUOPTIC VIS-1080 Series 80W True Hybrid Varifocal VIS-1080-SH8:
IR Wavelength 850 nm
Maximum Distance 689' (210 m) (White)
886' (270 m) (850 nm IR)
Maximum Illumination Angle 70° (White)
90° (IR)
Power 0 to 80 W (Adjustable)
Power Supply VIS-100-PWR (Recommended)
Input 20 to 29 VAC or 24 to 36 VDC, 1.7 A
Operating Temperature -40 to 122°F (-40 to +50°C)
Color Temperature 6,500 K
Certifications FCC, CE
IP66 water and dust resistant
Dimensions (HxWxD) 6.70 x 6.70 x 3.40" (17.01 x 17.01 x 8.63 cm)
Weight 4.4 lb (2.0 kg)
Packaging Info
Package Weight 6.1 lb
Box Dimensions (LxWxH) 12.0 x 9.0 x 6.0"
The user manual for the NUOPTIC VIS-1080 Series 80W True Hybrid Varifocal VIS-1080-SH8 can be downloaded in .pdf format if it did not come with your new illuminators, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other NUOPTIC users keep a unique electronic library for NUOPTIC illuminatorss, where you can use our link to download the user manual for the NUOPTIC VIS-1080 Series 80W True Hybrid Varifocal VIS-1080-SH8.

The user manual lists all of the functions of the NUOPTIC VIS-1080 Series 80W True Hybrid Varifocal VIS-1080-SH8, all the basic and advanced features and tells you how to use the illuminators. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from NUOPTIC service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the NUOPTIC VIS-1080 Series 80W True Hybrid Varifocal VIS-1080-SH8. User manuals are also available on the NUOPTIC website under Surveillance - Surveillance Video - Additional Accessories - Illuminators.
