User manual for the Optex DX-40 Wired Indoor Integrated Passive Infrared & DX-40

The user manual for the Optex DX-40 Wired Indoor Integrated Passive Infrared & DX-40 provides necessary instructions for the proper use of the product Surveillance - Alarm Systems - Motion Detectors.

Integrating PIR and microwave technology into attractive, easy-to-install units, the DX-40 Wired Indoor Integrated Passive Infrared & Microwave Detector from Optex provides stable and reliable detection in hostile environments, where simple PIR detectors struggle to function. The PIR element incorporates Quad Zone Logic to detect the smallest temperature contrast against the background temperature, thereby enabling it to discriminate between humans and other sources of infrared. Additionally, the microwave detector incorporates Microwave Area Shaping technology to prevent unwanted detection of movement outside the coverage area.
If you own a Optex motion detectors and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Optex DX-40 Wired Indoor Integrated Passive Infrared & DX-40 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Optex DX-40 Wired Indoor Integrated Passive Infrared & DX-40:
Specifications
    Technology Passive Infrared & microwave
    Installation Commercial, industrial
    Zones 82 zones (PIR) (interior)
    Coverage Wide 85°: 40 x 40' (12 x 12 m)
    Sensitivity 3.6°F (2.0°C) at (2'/second (0.6 m/second)), 40' (12 m)
    Speed Detectable Speed: 1 to 5'/second (0.3 to 1.5 m/second)
    Alarm Period: Approximately 30 seconds
    Output: N.C. 28 VDC, 0.2 A maximum
    Switch Tamper: N.C., open when cover is removed
    Warm-Up Period Approximately 30 seconds
    LED Flicker during warm-up
    Red: Alarm, alarm memory and trouble indicator
    Yellow: MW and trouble indicator
    Green: P.I.R and trouble indicator
    Power Supply 9 to 18 VDC
    Current Consumption 12 mA (normal), 35 mA (maximum) at 12 VDC
    RF Interference No alarm 30 V/m
    Operating Temprature 14 to 122°F (-10 to 50°C)
    Frequency 95% maximum
    Weather-Proof Rating Microwave: 9.900/10.525 GHz
    10.687 GHz (UK version)
    Mounting Height 5.0 x 8.0' (1.5 x 2.4 m)
    Dimensions 2.76 x 4.92 x 1.91" (70.00 x 125.00 x 48.60 mm)
    Weight 5.3 oz (150.0 g)
    The user manual for the Optex DX-40 Wired Indoor Integrated Passive Infrared & DX-40 can be downloaded in .pdf format if it did not come with your new motion detectors, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Optex users keep a unique electronic library for Optex motion detectorss, where you can use our link to download the user manual for the Optex DX-40 Wired Indoor Integrated Passive Infrared & DX-40.

    The user manual lists all of the functions of the Optex DX-40 Wired Indoor Integrated Passive Infrared & DX-40, all the basic and advanced features and tells you how to use the motion detectors. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Optex service.

    If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Optex DX-40 Wired Indoor Integrated Passive Infrared & DX-40. User manuals are also available on the Optex website under Surveillance - Alarm Systems - Motion Detectors.
