User manual for the PAG Ni-MH Pagbelt with Integral Overnight Charger 9230

The user manual for the PAG Ni-MH Pagbelt with Integral Overnight Charger 9230 provides necessary instructions for the proper use of the product Professional Video - Batteries & Power - Battery Belts, Packs & Power Stations.

The PAG Ni-MH Pagbelt with Integral Overnight Charger (30 V, 10 Ah) features an XLR-4 (F) output connector and a 10 A self-resetting thermal cut-out that protects the battery belt from accidental short circuit. Integrated ODP (Over Discharge Protection) feature (automatic low-voltage cut-out facility) prevents cell imbalance, providing long battery life.

The Ni-MH Pagbelt features a quick release buckle and a fully adjustable strap for ease of use and accessibility. For worldwide operation, you can use a fully isolated integral overnight charger that supports input supply from 100 to 250 VAC, 50 to 60 Hz.
If you own a PAG battery belts, packs & power stations and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the PAG Ni-MH Pagbelt with Integral Overnight Charger 9230 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the PAG Ni-MH Pagbelt with Integral Overnight Charger 9230:
Battery Cells Nickel-Metal Hydride sealed rechargeable cylindrical cells
Voltage 1.2 V per cell (nominal)
Capacity 9 Ah (measured at the five hour rate)
Over Discharge Protection PAG ODP circuit will trip at 22 to 24 V
Input/Output Connectors Output: Twin XLR-4 sockets wired in parallel
Pin 1 Negative (-)
Pin 2 No connection
Pin 3 No connection
Pin 4 Positive (+)
Input: Conforms to CEE22 and IEC 65
Operating Temperature 32 to 104ºF (0 to 40ºC)
Input Power 100 to 250 VAC @ 50 to 60 Hz (charger)
Output Voltage 40 VDC maximum (charger)
Power Consumption 50 W maximum (charger)
Output Current 1000 mA
Weight 12.1 lb (5.5 kg)
Packaging Info
Package Weight 20.0 lb
Box Dimensions (LxWxH) 24.0 x 18.0 x 8.0"
The user manual for the PAG Ni-MH Pagbelt with Integral Overnight Charger 9230 can be downloaded in .pdf format if it did not come with your new battery belts, packs & power stations, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other PAG users keep a unique electronic library for PAG battery belts, packs & power stationss, where you can use our link to download the user manual for the PAG Ni-MH Pagbelt with Integral Overnight Charger 9230.

The user manual lists all of the functions of the PAG Ni-MH Pagbelt with Integral Overnight Charger 9230, all the basic and advanced features and tells you how to use the battery belts, packs & power stations. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from PAG service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the PAG Ni-MH Pagbelt with Integral Overnight Charger 9230. User manuals are also available on the PAG website under Professional Video - Batteries & Power - Battery Belts, Packs & Power Stations.
