User manual Panasonic Lumix DMC-FZ300 Digital Camera DMC-FZ300

Operating instructions and pdf manual for use - Panasonic Lumix DMC-FZ300 Digital Camera DMC-FZ300 User manual, User manual Panasonic Lumix DMC-FZ300 Digital Camera DMC-FZ300, Panasonic, Lumix, DMC-FZ300, Digital, Camera, DMC-FZ300,


User manual for Panasonic Lumix DMC-FZ300 Digital Camera DMC-FZ300

Overall rating 4.5
Overall Rating: 4.5

90% of respondents would recommend this to a friend.
Panasonic Lumix DMC-FZ300 Digital Camera DMC-FZ300
  • Manufacturer: Panasonic
  • Basic description and contents of package
  • Product classification: Photography - Digital Cameras - Point & Shoot Cameras
  • Safety instructions
  • Startup and operation of the point & shoot cameras
  • Tips for setting up your Panasonic
  • Settings and expert assistance
  • Contact Panasonic service
  • Troubleshooting
  • Warranty information
  • Price: 498 USD
Panasonic Lumix DMC-FZ300 Digital Camera DMC-FZ300 Panasonic Lumix DMC-FZ300 Digital Camera DMC-FZ300 Panasonic Lumix DMC-FZ300 Digital Camera DMC-FZ300
Click to enlarge image

We recommend checking out our discussion threads on the Panasonic Lumix DMC-FZ300 Digital Camera DMC-FZ300, which address similar problems with connecting and setting up Point & Shoot Cameras Panasonic.



User manual for the Panasonic Lumix DMC-FZ300 Digital Camera DMC-FZ300

The user manual for the Panasonic Lumix DMC-FZ300 Digital Camera DMC-FZ300 provides necessary instructions for the proper use of the product Photography - Digital Cameras - Point & Shoot Cameras.

Blending an all-in one zoom, 4K video recording, and versatile still shooting capabilities, the Lumix DMC-FZ300 from Panasonic is a multi-faceted point-and-shoot optimized for the multimedia image maker. Featuring a 12.1 MP High-Sensitivity MOS sensor and Venus Engine image processor, the FZ300 is capable of recording up to 60 fps with an electronic shutter, 12 fps with a mechanical shutter, or 30 fps using the unique 4K Photo Modes. Working in low-light is benefitted by a top sensitivity of ISO 6400 along with 5-axis HYBRID O.I.S.+ image stabilization to minimize camera shake during HD video recording. The 24x Leica DC Vario-Elmarit lens covers a 25-600mm equivalent focal length range and has a constant f/2.8 maximum aperture for consistent performance from wide-angle to super telephoto. For composing imagery, configuring shooting settings, and reviewing your photos and movies, a large 3.0" 1.04m-dot free angle touchscreen LCD is available, as well as a 1.44m-dot OLED Live View Finder for eye-level monitoring. Able to handle nearly any image-related task, the FZ300 is a versatile camera well-suited to advanced photo and movie recording applications.

The body design features an ergonomic right-hand grip for added support when working with longer focal lengths, as well as a dust- and splash-proof construction to suit working in inclement conditions. Benefitting both stills and movies, Panasonic's DFD (Depth-From-Defocus) AF system helps to quicken focusing speeds while a Starlight AF feature maintains focusing accuracy in low-light conditions. And benefitting both sharing and shooting control, Wi-Fi connectivity allows for wireless image sharing and remote camera control from smartphones and tablets.
If you own a Panasonic point & shoot cameras and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Panasonic Lumix DMC-FZ300 Digital Camera DMC-FZ300 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Panasonic Lumix DMC-FZ300 Digital Camera DMC-FZ300:
Specifications
Imaging
Pixels Actual: 12.8 Megapixel
Effective: 12.1 Megapixel
Sensor 1/2.3" MOS
File Formats Still Images: JPEG, RAW
Movies: AVCHD Ver. 2.0, MP4
Audio: AAC
Max Resolution 12 MP: 4000 x 3000
Aspect Ratio 1:1, 3:2, 4:3, 16:9
Image Stabilization Optical, 5-Way
Optics
Lens Leica DC Vario-Elmarit, 14 elements in 11 groups
5 Aspherical, 3 ED
EFL: 4.5-108mm (35 mm equivalent: 25-600mm)
Aperture: f/2.8 to f/8
Filter Thread 52mm
Zoom Optical: 24x
Intelligent Zoom: 2x
Extra Optical Zoom (EZ): 1.23x
Extra Optical Zoom (EZ): 1.95x
Digital: 4x
Focus Range Wide: 11.81" (30 cm) - Infinity
Telephoto: 6.56' (2 m) - Infinity
Wide Macro: 0.39" (1 cm) - Infinity
Tele Macro: 3.28' (1 m) - Infinity
Exposure Control
ISO Sensitivity Auto, 100-6400
Shutter Type: Mechanical
Speed: 60 - 1/4000 second
Type: Electronic
Speed: 1 - 1/16000 second
60 - 0 second in  Bulb Mode
1/2 - 1/16000 second in  Movie Mode
Exposure Metering Center-weighted, Multi, Spot
Exposure Modes Modes: Aperture Priority, Manual, Programmed Auto, Shutter Priority
Compensation: -3 EV to +3 EV (in 1/3 EV steps)
White Balance Modes Auto, Cloudy, Color Temperature, Daylight, Flash, Incandescent, Shade, White Set 1, White Set 2, White Set 3, White Set 4
Continuous Shooting Up to 60 fps at 12.1 MP  frames
Up to 12 fps at 12.1 MP  frames
Up to 6 fps at 12.1 MP  frames
Up to 2 fps at 12.1 MP  frames
Up to 30 fps at 8 MP for up to 53,970 frames
Self Timer 10 Sec, 2 Sec
Flash
Flash Modes Auto
Auto/Red-eye Reduction
Forced On
Forced On/Red-eye Reduction
Off
Slow Sync
Slow Sync/Red-eye Reduction
Built-in Flash Yes
Maximum Effective Flash Range Wide: 0.98 - 28.87' (0.3 - 8.8 m)
Telephoto: 3.28 - 28.87' (1.0 - 8.8 m)
External Flash Connection Hot Shoe
Memory
Memory Card Type SD
SDHC
SDXC
Recording
Video Recording Yes, NTSC
Resolution 3840 x 2160p: 30 fps, 24 fps
1920 x 1080p: 60 fps, 30 fps
1280 x 720p: 120 fps, 30 fps
640 x 480p: 240 fps, 30 fps
Video
Video Clip Length Up to 29 Sec 59 Sec
Audio Recording Built-in Mic: With Video, Stereo
Optional External Mic: With Video
Viewfinder/Display
Viewfinder Type Electronic
Viewfinder Coverage 100%
Screen 3.0" LCD Rear Touch Screen Swivel (1,040,000 pixels)
Screen Coverage 100%
Connectivity/System Requirements
Connectivity AV Output, HDMI D (Micro), USB 2.0
Wi-Fi Yes, 802.11b/g/n built-in
Power
Battery 1x Rechargeable Lithium-Ion Battery Pack, 7.2 VDC, 1200 mAh
Physical
Dimensions (WxHxD) 5.2 x 3.6 x 4.6" / 131.6 x 91.5 x 117.1 mm
Weight 1.52 lb / 691 g with battery and memory card
Packaging Info
Package Weight 2.85 lb
Box Dimensions (LxWxH) 7.6 x 6.3 x 4.9"
The Panasonic Lumix DMC-GX8 & DMC-FZ300: First Look
The user manual for the Panasonic Lumix DMC-FZ300 Digital Camera DMC-FZ300 can be downloaded in .pdf format if it did not come with your new point & shoot cameras, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Panasonic users keep a unique electronic library for Panasonic point & shoot camerass, where you can use our link to download the user manual for the Panasonic Lumix DMC-FZ300 Digital Camera DMC-FZ300.

The user manual lists all of the functions of the Panasonic Lumix DMC-FZ300 Digital Camera DMC-FZ300, all the basic and advanced features and tells you how to use the point & shoot cameras. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Panasonic service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Panasonic Lumix DMC-FZ300 Digital Camera DMC-FZ300. User manuals are also available on the Panasonic website under Photography - Digital Cameras - Point & Shoot Cameras.
