The MT454-PSTNP Octopus USB Base Unit with Analog Telephone Interface & Power Amplifier from Phoenix Audio is an audio conferencing mixer with four XLR mic/line inputs. It can be used in applications for conference rooms, classrooms, training rooms, courtrooms, depositions, and more.
If you own a Phoenix Audio audio conferencing and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Phoenix Audio MT454-PSTNP Octopus USB Base Unit MT454-PSTN-PA in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Phoenix Audio MT454-PSTNP Octopus USB Base Unit MT454-PSTN-PA:
Specifications
    Inputs
    Designation Mic (mixer inputs), auxiliary, sound reinforcement
    Number of Inputs 4x
    Phantom Power User Selectable: 3 V, 24 V, or none (for line inputs)
    Connectors XLR
    Input Impedance Phantom 3 V: 2 kOhms
    Phantom 24 V: 590 ohms
    No Phantom: 2 kOhms
    Maximum Input Level 1.8 V/gain
    Gain User Selectable: 0 to 42 db in 6 dB steps
    Frequency Response 20 Hz to 16 kHz
    Audio Output
    Connectors RCA
    XLR (the XLR is re-assigned as link-up when the unit is configured as slave)
    Level Line or mic level (user selectable)
    Line Level 1.8 V pp max
    Mic Level Output 90 mV pp max
    Link-Up Level Line (1.8 V pp fixed)
    Impedance 25 ohms
    Frequency Response 20 Hz to 16 kHz
    Audio Input
    Connector RCA
    Impedance 100 kOhms
    Level 1.8 V pp
    Loudspeaker Outputs
    Connector 2-pin terminal block
    Impedance 25 ohms
    Level 1.8 V pp max
    Com Ports RS232
    Power 5V, 200 mAmp (through the USB connector)
    Physical Characteristics
    Dimensions (L x W x D) 8 x 16.5 x 1.75" (20.3 x 41.9 x 4.4 cm)
    Weight 5.65 lb (2.6 kg)
    Packaging Info
    Package Weight 8.15 lb
