The black Quantum HD19A 16mm Thermal Monocular from Pulsar is intended for detection and monitoring of heat emanating from wildlife, game, animal stock, faulty wiring and piping, structural and insulation defects, running engines and human bodies. With this device you can see those heat sources through fog, smoke and haze. The imager features a micro-bolometer sensor with a resolution of 384x288 pixels, and 7.7µm to 13.2µm spectral sensitivity. It is capable of displaying thermal images at a frame rate of 30 Hz using a built-in 640x480 pixel LCD display, an external monitor or a recording device. The optical system features a 16mm f/1.2 germanium lens that provides 1x optical zoom and allows for a wide angular field of view. If you need a close-up of your target, the camera also has a digital zoom of 2x . While opaque in the visible spectrum, the germanium lens has high transmission in the long infrared region, which makes it ideal for thermal imaging. The housing is made of lightweight and durable glass-nylon composite and has a texture with coarse deep groves to allow a good grip. The control buttons are arranged in a staggered configuration to for an easy reach and one-handed operation with either left or right hand. This thermal imager can also be mounted on a tripod via a top or a bottom 1/4"-20 sockets. Additionally, it has a Weaver style mount adapter for connecting accessories. The objective is outfitted with a flip-out objective lens cap to protect the germanium lens from damage and elements. The eyepiece has a diopter adjustment and a rubberized winged eye-cap. Also included are a carrying case, a hand strap, a car adapter, an extra battery container, and a lens cloth.
|
If you own a Pulsar thermal imagers and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Pulsar Quantum HD19A 16mm Thermal Monocular PL77325 in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
|
Additional parameters of the Pulsar Quantum HD19A 16mm Thermal Monocular PL77325:
Sensor | Microbolometer Resolution: 384x288 pixels Band: LWIR Spectral Range: 7.7 - 13.2 µm Pixel pitch: 25 µm | Detection Range | 515 yd (470 m) | Display | Type: LCD Diagonal: 0.31" Frame rate: 30 Hz Resolution: 640x480 pixels Format: PAL, NTSC Connector: 3.5 mm jack | Magnification | Optical: 1x Digital zoom: 2x | Lens System | 16mm f/1.2 Germanium | Angular Field of View | Horizontal: 27° Vertical: 21° | Linear Field of View | Horizontal: 152' @ 100 yd (50.5 @ 100 m) Vertical: 114' @ 100 yd (38 @ 100 m) | Minimum Focus Distance | 10' (3 m) | Eye Relief | 0.8" (20 mm) | Exit Pupil | 5 mm | Diopter Adjustment | ±5 | Battery / Runtime | 4 x AA / 5.5 hr max | Material of Construction | Glass-nylon composite | Tripod | 2 x 1/4"-20 | Mount | Weaver | Operating Temperature | 5 to 122°F (- 15 to 50°C) | Dimensions | 7.1 x 3.4 x 2.3" (180 x 86 x 58 mm) | Weight | 11.3 oz (321 g) | |
