User manual for the QSC WL3082 WideLine-8 Line Array Loudspeaker (White) WL3082-WH
The user manual for the QSC WL3082 WideLine-8 Line Array Loudspeaker (White) WL3082-WH provides
necessary instructions for the proper use of the product Pro Audio - Live Sound - PA Speakers.
The white WL3082 WideLine-8 Line Array Loudspeaker from QSC uses two high-power, neodymium magnet, 2.4" voice-coil, 8" low-frequency drivers in a two-and-a-half way configuration.
Both woofers produce low-frequencies. One of the woofers covers the mid-range for increased horizontal directivity control in the crossover region. The 3" voice coil neodymium magnet compression driver with a titanium diaphragm allows for a high-frequency output and clarity.
The compression driver is mounted to a multiple-aperture diffraction waveguide that provides a wide horizontal coverage of 140°. The low-frequency capability of a WL3082 array extends to 62 Hz (-10 dB) which is adequate for speech/vocal and acoustic music program material.
If you own a QSC pa speakers and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the QSC WL3082 WideLine-8 Line Array Loudspeaker (White) WL3082-WH in the following formats:
*.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the QSC WL3082 WideLine-8 Line Array Loudspeaker (White) WL3082-WH:
Specifications
Configuration
Dual 8", 3-way, tri-amp line-array
High Frequency Transducer
3" diaphragm, neodymium magnet compression driver
Low Frequency Transducer
Dual, 8" woofer, 2.4" voice coil
Frequency Response
68 Hz to 18 kHz ±3 dB
Frequency Range
62 Hz to 20 kHz @ -10 dB
Nominal Impedance
HF: 16 ohms MF: 16 ohms LF: 16 ohms
Power Capacity
HF: 85 W MF: 250 W LF: 250 W
Continuous
Sensitivity
HF: 108 dB SPL MF: 98 dB SPL LF: 98 dB SPL
1 W @ 3.3' (1 m)
Maximum Output
Continuous/Peak: HF: 127 dB SPL / 133 dB SPL MF: 122 dB SPL / 128 dB SPL LF: 122 dB SPL / 128 dB SPL
dB SPL @ 3.3' (1 m)
Nominal Coverage Angle
Horizontal: 140° Vertical: Dependent on number of elements used
Enclosure Type
Ported, trapezoidal
Enclosure Material
15 mm birch plywood
Finish
Textured white
Grille
Perforated, 16AWG steel, backed with white cloth fabric
Connectors
2 x NL8 in parallel Pinout: 1+/1- NC 2+/2- LF 3+/3- MF 4+/4- HF
Attachment
Integral, side plate adjustable rigging system, vertical splay adjustable in 1° increments from 0° to 10°
Dimensions
9 x 20 x 16" (229 x 508 x 406 mm)
Weight
38 lb (17 kg)
