The black TT25-A II 2-Way Active High-Output Speaker from RCF is an active, 2-way, sound-reinforcement speaker that features a 15" neodymium woofer, 86mm voice coil in a bass reflex configuration, and a 1.4” exit, 75mm voice coil neo-compression driver. It also features two independent digital amplifiers, one with 800W for low frequencies and the other with 300W for the high-frequency driver. The Class-D amplifiers offer hi-fi sound, extremely low distortion with negligible quiescent noise, and stable burst response. The TT25-A II is equipped with a state-of-the-art input board which features XLR In/Out, a rotating encoder for gain reduction, time delay, speaker presets, RDNet input/output, 4 status LEDs, and a Powercon input/output.

The woofer features 32-bit/96 kHz,  DSP processing and a networking board. With DSP on board each cabinet, the unit can be configured to address to single cabinets or groups of cabinets with specific presets or modifications of parameters like gain, equalization, or delay. The RDNet protocol is based on RS-485 communication protocol, which is very stable, and it is possible to send and receive data on a simple XLR cable.

The TT+ two-way system features a multi-functional rear encoder to easily control all the speaker functions (gain reduction, delay, speaker presets), even without network connection. The speaker is equipped with a complete set of integrated rigging mechanics for rental or installation.
If you own a RCF pa speakers and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the RCF TT25-A II 2-Way Active High-Output Speaker (Black) TT25-A II in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the RCF TT25-A II 2-Way Active High-Output Speaker (Black) TT25-A II:
Acoustical
Frequency Response -3 dB: 50 Hz to 20 kHz
Maximum SPL 134 dB
Angle Horizontal: 90°
Vertical: 60°
Compression Driver 1.5", 4.0" voice coil
Woofer 15", 3.5" voice coil
Input/Output
Input Signal Balanced/unbalanced
Input Connectors XLR, RDNet on-board
Input Sensitivity -2 dBu / + 4 dBu
Processor
Crossover Frequencies 800 Hz
Protections Thermal, HF
Limiter Fast limiter, dynamic
Amplifier
Total Power 1100 W RMS
Frequencies High: 300 W RMS
Low: 800 W RMS
Cooling Convection
Connection VDE connector
Cabinet
Material Baltic birch plywood
Handles 2 side
Pole Mount/Cap Yes
Physical
Dimensions (H x W x D) 27.0 x 17.0 x 17.0" (69 x 43.2 x 43.2 cm)
Weight 57.3 lb (26.0 kg)
The user manual for the RCF TT25-A II 2-Way Active High-Output Speaker (Black) TT25-A II can be downloaded in .pdf format if it did not come with your new pa speakers, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other RCF users keep a unique electronic library for RCF pa speakerss, where you can use our link to download the user manual for the RCF TT25-A II 2-Way Active High-Output Speaker (Black) TT25-A II.
