User manual Samson UM1/77 Videographer Combo Pack Wireless SW87SHQ7LM5-N3

Operating instructions and pdf manual for use - Samson UM1/77 Videographer Combo Pack Wireless SW87SHQ7LM5-N3 User manual, User manual Samson UM1/77 Videographer Combo Pack Wireless SW87SHQ7LM5-N3, Samson, UM1/77, Videographer, Combo, Pack, Wireles


User manual for Samson UM1/77 Videographer Combo Pack Wireless SW87SHQ7LM5-N3

Samson UM1/77 Videographer Combo Pack Wireless SW87SHQ7LM5-N3
  • Manufacturer: Samson
  • Basic description and contents of package
  • Product classification: Pro Audio - Location Sound - Wireless Systems
  • Safety instructions
  • Startup and operation of the wireless systems
  • Tips for setting up your Samson
  • Settings and expert assistance
  • Contact Samson service
  • Troubleshooting
  • Warranty information
  • Price: 300 USD
We recommend checking out our discussion threads on the Samson UM1/77 Videographer Combo Pack Wireless SW87SHQ7LM5-N3, which address similar problems with connecting and setting up Wireless Systems Samson.



User manual for the Samson UM1/77 Videographer Combo Pack Wireless SW87SHQ7LM5-N3

The user manual for the Samson UM1/77 Videographer Combo Pack Wireless SW87SHQ7LM5-N3 provides necessary instructions for the proper use of the product Pro Audio - Location Sound - Wireless Systems.

The UM1/77 Videographer Combo Pack Wireless System from Samson is designed to provide commercial videographers and corporate and broadcast video professionals with both handheld and hands-free wireless miking options. It includes the camera-mountable UM1 wireless Micro receiver, the CT7 belt-pack transmitter with an LM5 omnidirectional lavalier mic, an HT7 handheld transmitter with a Q7 supercardioid capsule, a mini-XLR to XLR cable, a 1/8" TRS cable, a stand clip, a hook and loop fastener mounting strip, and a foam-lined hardshell carry case. The combo pack is tuned to Samson's N3 frequency band and operates on 644.125 MHz.

The UM1 receiver features true diversity reception and has a balanced mini-XLR and an unbalanced 1/8" TRS output that can be switched between mic and line level for connecting to a variety of recording destinations. Both the CT7 belt-pack transmitter and the HT7 handheld have separate on/off and mute switches in addition to variable gain control. The system operates within a 300-foot line of sight range and allows you to select the appropriate transmitter for a given application.
If you own a Samson wireless systems and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Samson UM1/77 Videographer Combo Pack Wireless SW87SHQ7LM5-N3 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
User manual for Samson UM1/77 Videographer Combo Pack Wireless SW87SHQ7LM5-N3Download user manual for Samson UM1/77 Videographer Combo Pack Wireless SW87SHQ7LM5-N3
(PDF file, 0.25 MB)
Additional parameters of the Samson UM1/77 Videographer Combo Pack Wireless SW87SHQ7LM5-N3:
Receiver
Frequency Response 50 Hz to 15 kHz (+/- 3 dB overall)
Receiving Frequency 644.125 MHz
Squelch Sensitivity: 17 dBμv ±4 dB
THD 1 % Maximum (@AF 1 kHz, RF 56 dBuv), overall
Dimensions (W x D x H) 2.6 x 1 x 4.25" (65.8 x 26 x 107 mm)
Handheld Transmitter
Frequency Response 50 Hz to 16 kHz
Sensitivity -54 dB
Impedance 200 Ω
Maximum SPL 150 dB
Connector 3-pin gold-plated balanced male XLR
Dimensions (Ø x L) 2.09 x 6.09" (53 x 180 mm)
Weight 13 oz (368 g)
Bodypack Transmitter
Frequency Response 50 Hz to 15 kHz (± 3.5 dB)
Current Consumption 7 mA typical
Battery Life 12 hours (9 V battery)
RF Output Power -4 dB Minimum, 3 dB Maximum (5 mW)
Frequency Stability +/- 20 kHz
Dimensions (W x D x H) 2.6 x 0.92 x 4" (66.15 x 23.4 x 102.5 mm)
Microphone
Type Q7 Capsule: Dynamic
Frequency Response Q7 Capsule: 80 Hz to 12 kHz
Polar Pattern Q7 Capsule: Supercardioid
LM5: Omnidirectional
Output Impedance Q7 Capsule: 200 Ω
Sensitivity Q7 Capsule: -54 dBV/Pa (2.2 mv/pa)
Packaging Info
Package Weight 4.5 lb
Box Dimensions (LxWxH) 15.7 x 12.0 x 2.7"
The user manual for the Samson UM1/77 Videographer Combo Pack Wireless SW87SHQ7LM5-N3 can be downloaded in .pdf format if it did not come with your new wireless systems, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Samson users keep a unique electronic library for Samson wireless systemss, where you can use our link to download the user manual for the Samson UM1/77 Videographer Combo Pack Wireless SW87SHQ7LM5-N3.

The user manual lists all of the functions of the Samson UM1/77 Videographer Combo Pack Wireless SW87SHQ7LM5-N3, all the basic and advanced features and tells you how to use the wireless systems. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Samson service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Samson UM1/77 Videographer Combo Pack Wireless SW87SHQ7LM5-N3. User manuals are also available on the Samson website under Pro Audio - Location Sound - Wireless Systems.
