The Platinum Series SS-660XP2 Active PFC F3 660W Power Supply Unit from Sea Sonic Electronics is designed for high-performance PCs where reliability is essential. It offers tight voltage regulation (±2%), virtually silent operation, and a fully-modular design. The 80 PLUS Platinum efficiency ensures power savings with up to 92% efficiency at 50% operating load.
If you own a SeaSonic Electronics power supplies and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the SeaSonic Electronics Platinum Series PLATINUM-660 SS-660XP2 in the following formats:
*.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the SeaSonic Electronics Platinum Series PLATINUM-660 SS-660XP2:
Specifications
Compliance
Intel ATX12V / EPS12V
80 PLUS Certification Level
Platinum
Power Efficiency
>90, 92, and 89% efficiency at 20, 50, and 100% operating load respectively
AC Input Range
100 to 240 V, 8.5 to 4 A, 50/60 Hz
DC Output
Total: 660 W
Load
At +3.3 & +5 VDC Output: Maximum Load: 25 A Combined Load: 125 W
At +12 VDC Output: Maximum Load: 55 A Combined Load: 660 W
At -12 VDC Output: Maximum Load: 0.5 A Combined Load: 6 W
At +5 Vsb DC Output: Maximum Load: 3 A Combined Load: 15 W
Connectors
1 x 20/24-pin motherboard power [24" (610 mm)] 1 x 6/8-pin EPS12V / ATX12V [25.5" (650 mm)] 1 x 8-pin EPS12V [25.5" (650 mm)] 4 x 6/8-pin PCIe [23.6" (600 mm)] 5 x 4-pin Peripheral 10 x SATA 1 x 4-pin floppy (Y-adapter)
