When capturing audio the QLXD4 Digital Wireless Receiver by Shure offers 24-bit digital audio quality and good RF spectrum reception. When paired with a wireless transmitter and microphone, it can be used for mid-size events and installations in businesses, hotels, government offices, schools, houses of worship, live performance spaces, and more. It features more than 60 preset channels per frequency band, network control, and AES-256-bit encryption. The QLXD4 wireless receiver is built with switching diversity and automatic channel scan, and has IR one-touch sync capabilities to make finding an open frequency quick. This receiver features a 20 Hz to 20 kHz frequency range, and a high-contrast LCD display. This allows for clear navigation though the menus and controls. With clearly defined performance, the QLXD4 delivers good clean audio and provides professional features for demanding live sound events and installations.
If you own a Shure wireless receivers and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Shure QLXD4 Digital Wireless Receiver QLXD4-G50 in the following formats:
*.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Shure QLXD4 Digital Wireless Receiver QLXD4-G50:
328' (100 m) Note: Actual range depends on RF signal absorption, reflection and interference
RF
Tuning Step Size: 25 kHz, varies by region
Image Rejection
Greater than 70 dB, typical
RF Sensitivity
−97 dBm at 10-5 BER
Latency
Less than 2.9 ms
Audio Frequency Response
QLXD1: 20 Hz - 20 kHz (±1 dB) QLXD2: Dependent on microphone type
Audio Dynamic Range
System Gain @ +10: Greater than 120 dB, A-weighted, typical
Total Harmonic Distortion (THD)
−12 dBFS Input, System Gain @ +10: Less than 0.1%
Polarity
System Audio: Positive pressure on microphone diaphragm produces positive voltage on pin 2 (with respect to pin 3 of XLR output) and the tip of the 6.35 mm (1/4-inch) output
Operating Temperature Range
0 to 122°F (-18 to 50°C) Note: Battery characteristics may limit this range
Storage Temperature Range
-20 to 165°F (-29 to 74°C) Note: Battery characteristics may limit this range.
Gain Adjustment Range: -18 to +42 dB in 1 dB steps Configuration: 1/4" (6.35 mm), Impedance balanced (Tip=audio, Ring=no audio, Sleeve=ground) XLR: Balanced (1=ground, 2=audio +, 3=audio −) Impedance 1/4" (6.35 mm), 100 ohms (50 ohms Unbalanced) XLR: 100 ohms Full Scale Output: 1/4" (6.35 mm), +12 dBV XLR: LINE setting= +18 dBV, MIC setting= −12 dBV Mic/Line Switch: 30 dB pad Phantom Power Protection: 1/4" (6.35 mm), Yes XLR: Yes
Networking
Network Interface: Single Port Ethernet 10/100 Mbps Network Addressing Capability: DHCP or Manual IP address Maximum Ethernet Cable Length: 328' (100 m)
Power Requirement
12 VDC @ 0.4 A, supplied by external power supply (tip positive)
